Y-ASK-RH850F1KM-S4-V3 is a RH850/F1KM-S4 starter kit. The 'RH850/F1KM-S4 Starter Kit' serves as a simple and easy to use platform for evaluating the features and performance of Renesas Electronics' 32bit RH850/F1KM-S4 microcontrollers. Typical applications include parking assistance system with AHL camera and automotive monitoring function extension for motor control system.
- Connections for on-chip debugging and flash memory programming
- Access to all microcontroller I/O pins
- User interaction through potentiometer, rotary switch, buttons and LEDs
- Serial interface connections for 1x RS232, 1x LIN, 2x CAN-FD, 1x FlexRay, 1x Ethernet 100Base-T
- Power supply by RENESAS E1 on-chip debugger or externally (12V DC input)
Other details
| Brand |
RENESAS |
| Part Number |
Y-ASK-RH850F1KM-S4-V3 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
