R5F51115AGFL#5A is a RX100 Series, RX111 group 32bit microcontroller with small-capacity ROM/low pin count line-up and built-in USB 2.0. With USB 2.0 for battery charging (BC 1.2), low consumption current and fast wakeup from standby, this microcontroller is suitable for use in computer peripherals, and healthcare and wearable devices. With their three-phase motor control timers, it is also suitable for motor control applications in home appliances and industrial equipment.
- 32bit RX CPU core and 32MHz maximum operating frequency
- 128Kbytes/16Kbytes/8Kbytes ROM, RAM, and E2 DataFlash capacity
- Low power consumption functions, operation from a single 1.8 to 3.6V supply
- Data transfer controller (DTC), event link controller (ELC) and Independent watchdog timer (IWDT)
- POR, LVD reset and power supply voltage management
- Memory protect, unique ID security and encryption
- On-chip functions for IEC 60730 compliance
- Up to six channels for communication
- 0.5mm 48 pin LFQFP package
- Operating temperature range from -40°C to +105°C
Product details
| Product Range:
RX Family, RX100 Series, RX111 Group Microcontrollers
|
| Device Core:
RX
|
| Data Bus Width:
32 bit
|
| Operating Frequency Max:
32MHz
|
| Program Memory Size:
128KB
|
| No. of Pins:
48Pins
|
| IC Case / Package:
LFQFP
|
| No. of I/O's:
30I/O's
|
| Interfaces:
I2C, SPI, UART, USB
|
| RAM Memory Size:
16KB
|
| ADC Channels:
14Channels
|
| ADC Resolution:
12Bit
|
| Supply Voltage Min:
1.8V
|
| Supply Voltage Max:
3.6V
|
| Operating Temperature Min:
-40°C
|
| Operating Temperature Max:
85°C
|
| IC Mounting:
Surface Mount
|
| MCU Family:
RX
|
| MCU Series:
RX100
|
| Qualification:
-
|
Other details
| Brand |
RENESAS |
| Part Number |
R5F51115AGFL#5A |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
