Wide input range dual PWM controller with DDR option. Suitable for single and dual channel DDR memory power systems, graphics cards - GPU and memory supplies, supplies for servers, motherboards, FPGAs, ASIC power supplies, embedded processor and I/O supplies, DSP supplies applications.
- Provides regulated output voltage in the range of 0.9V to 5.5V
- Complete DDR memory power solution with VTT tracks VDDQ/2 and VDDQ/2 buffered reference output
- Supports both DDR-I and DDR2 memory
- Lossless rDS(ON) current-sense sensing
- Excellent dynamic response with voltage feed-forward and current mode control
- Dual mode operation - operates directly from a 5.0V to 15V input or 3.3V/5V system rail
- Undervoltage lock-out on VCC pin
- Power-good, overcurrent, overvoltage, undervoltage protection for both channels
- Synchronized 300KHz PWM operation in PWM mode
Footnotes Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Other details
| Brand |
RENESAS |
| Part Number |
ISL6539CAZ |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
