Provided by third party: The BDSv4u design takes the system to another level of functionality. The RM can turn on and off the BDSv4u remotely while displaying the voltage of the power source and the amperage draw of the connected equipment.
- Key Features
-
- Helping prevent accidental short circuits
- USB port
- Helping prevent accidental short circuits
- This connector set was chosen for its strength and so that unused (exposed) outlets on the box are not active until a cable with the proper mating connector is plugged into it, helping prevent accidental short circuits.
- USB port
- The BDSv4u has a standard USB port to facilitate charging or powering anything that will run or charge via USB, such as a smartphone or handheld recorder.
| General |
| Device Type | Power distribution unit - external |
| Power Device |
| Input Connectors | 4 pin mini XLR |
| Power Output Connectors Details | 6 x 4 pin Hirose
1 x 4 pin USB Type A - 5 V - 2 A |
| Output Voltage | DC 12 V |
| Max Electric Current | 5 A |
| Power Capacity | 60 Watt |
| Circuit Protection | Circuit breaker |
| Miscellaneous |
| Features | On/off switch, overload protection, short-circuit protection, reverse polarity protection |
| Packaging Info |
| Package Weight | 0.25 lb |
| Box Dimensions (LxWxH) | 7.1 x 2.6 x 1.7" |
