Provided by third party: High intelligibility, high efficiency and compact design make the RCF MQ80P 2-way horn-loaded sound projector speaker system the ideal solution to get clear voice and music reproduction in mid-size environment. Suitable for PA systems and background/foreground music systems. Thanks to its 90� x 60�constant directivity and to simple accessories it can be combined in clusters of 2 or more pieces to get wide and smooth coverage and to reduce the installation points. The woofer is a high-excursion, PP coated paper cone - rubber surround design mounted in a tuned enclosure (port can be sealed for full outdoor installation).
The tweeter is a horn-loaded compression driver with phase plug, the only way to get real and crispy intelligible voice reproduction even in wide and noisy environments. Installation of the MQ80P is quick thanks to the unique bracket with several fixing points and aiming facilities.Connections are made by a multi-pole cable. Wattage taps and voltage adjustments together with 8-Ohm operation are selectable by means of a Rotary switch, accessible under a sealed cover. The enclosure is constructed of high-density UV-resistant self-extinguishing polystyrene with robust steel grill.
| General |
| Product Type | Speaker - for PA system |
| Protection | UV radiation resistant |
| Width | 7.5 in |
| Depth | 9.3 in |
| Height | 8.8 in |
| Weight | 8.05 lbs |
| Enclosure Color | White |
| Enclosure Material | Steel, self-extinguishing polystyrene |
| Speaker System |
| Speaker Type | 2-way - passive |
| Nominal Output Power | 60 Watt |
| Max (RMS) Output Power | 120 Watt |
| Frequency Response | 100 - 20000 Hz |
| Nominal Impedance | 8 Ohm |
| Output Level (SPL) | 115 dB |
| Sensitivity | 94 dB |
| Crossover Frequency | 3000Hz |
| Integrated Transformer | 70.7V/100V or 8 Ohm operation |
| Coverage | 90� x 60� |
| Recommended Placing | Indoor / outdoor |
| Speaker System Details |
| Driver Details | Speaker: 1 x woofer driver - 5" - polypropylene treated paper
Speaker: 1 x tweeter driver - 1" - Horn Loaded Compression Driver (HLCD) |
