Description
Features & Specs
- Vesper Technologies VM1010
- Piezoelectric MEMS microphone
- ZeroPower ListeningTM: 300Hz - 6kHz
- Min Acoustic Threshold: 65 dB SPL
- Max Acoustic Threshold: 89 dB SPL
- Start-up time: 50 microseconds
- Dust and water resistant to IP57
- Operating Temperature Range: -40 to +85 °C
- Supply Voltage: 1.6VMin, 1.8VTyp, 3.6VMax
- PCA9536 GPIO expander
- I2C address: 0x41
- Supply Voltage: 2.3VMin, 5.5VMax
- Note: Qwiic bus operates at 3.3VMax
- Breakout pads for:
- I2C
- DOUT / Trigger
- MODE / Reset
- Gain adjustment
- Analog audio output
- VOUT bias is 0.8V
- Power LED
- Trigger LED
Features & Specs
- Vesper Technologies VM1010
- Piezoelectric MEMS microphone
- ZeroPower ListeningTM: 300Hz - 6kHz
- Min Acoustic Threshold: 65 dB SPL
- Max Acoustic Threshold: 89 dB SPL
- Start-up time: 50 microseconds
- Dust and water resistant to IP57
- Operating Temperature Range: -40 to +85 °C
- Supply Voltage: 1.6VMin, 1.8VTyp, 3.6VMax
- PCA9536 GPIO expander
- I2C address: 0x41
- Supply Voltage: 2.3VMin, 5.5VMax
- Note: Qwiic bus operates at 3.3VMax
- Breakout pads for:
- I2C
- DOUT / Trigger
- MODE / Reset
- Gain adjustment
- Analog audio output
- VOUT bias is 0.8V
- Power LED
- Trigger LED
Documentation
- Sound Location Tutorial - Part 1
- Sound Location Tutorial - Part 2
- Schematic
- Eagle Files
- Hardware Repo
