Description
QVS VC5-1P Overview
The VC5-1P VGA/QXGA Video over CAT5e Single-Power Extender Kit from QVS extends video signals up to 262' away via a CAT5e cable. It includes a transmitter unit and a receiver unit, a power adaptor, and a 3' HD15 M/M cable. This extender kit provides equalization and video signal gain adjustment. It supports resolutions of 2048 x 1536/60 Hz for up to 164' and 1280 x 1024/60 Hz for up to 262' away. It can be powered from either the transmitter or receiver module. This extender kit connects any VGA/QXGA video display to any computer, projector, LCD, switch, or distribution amplifier.
Transmit video using a CAT5e/6 cable
Powered from either the transmitter or receiver module
Receiver module provides equalization and gain controls
Supports VGA/QXGA up to 2048 x 1536 @ 60 Hz
FCC, CE and RoHS compliant
UPC: 037229007299
In the Box
- QVS VC5-1P VGA/QXGA Video over CAT5e Single-Power Extender Kit
- Power Adaptor
- Limited 1-Year Manufacturer Warranty
QVS VC5-1P Specs
| Signal Type | VGA/SVGA, XGA/UXGA |
| Distance | Up to 262' (80 m) |
| Video Bandwidth | Up to 150 MHz |
| Connectors | Transmitter: 1 x 15-pin Sub-D, VGA input 1 x RJ45 Receiver: 1 x 15-pin Sub-D, VGA output 1 x RJ45 |
| Compatibility | PC & LCD |
| Insertion Loss | < 3 dB |
| Impedance | RGB: 75 ohms, unbalanced CAT5e: 100 ohms, balanced |
| Video Signal Return Loss | -15 dB max from DC to 60 MHz |
| Cable Equalization | CAT5e: Adjustable EQ controls |
| Operating Temperature | 32 to 131°F (0 to 55°C) |
| Certification and Compliance | RoHs, FCC, and CE |
Packaging Info
| Package Weight | 1.543 lb |
| Box Dimensions (LxWxH) | 9.6 x 6.1 x 2.7" |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 22530.2 |
| 3-5 | ₹ 22300.3 |
| 5-10 | ₹ 21840.5 |
| 10+ | ₹ 21380.7 |
Bulk discount will be automatically applied during checkout based on quantity.
