Description
Features & Specs
- Dimensions: 12.2 x 16 x 2.6mm
- Weight: Approx. 0.9g
- Operating Temperature: -40°C - +85°C
- Supported Bands:
- GPS: L1 C/A, L5, L2C
- GLONASS: L1, L2
- Galileo: E1, E5a, E5b, E6
- BDS: B1I, B1C, B2a, B2b, B2I, B3I
- QZSS: L1 C/A, L5, L2C
- NavIC: L5
- SBAS: L1
- Default Constellations: GPS + GLONASS + Galileo + BDS + QZSS + NavIC
- Number of Tracking Channels: 1040
- Number of Concurrent GNSS: 5 + QZSS
- Horizontal Position Accuracy:
- Autonomous: 0.7m
- RTK: 0.8cm + 1ppm
- Vertical Accuracy:
- Autonomous: 2.5m
-
- RTK: 1.5cm + 1ppm
- Velocity Accuracy (Without Aid): 0.03m/s
- Accuracy of 1PPS Sognal (RMS): 5ns
- RTK Convergence Time: 5s
- TTFF (without AGNSS):
- Cold Start: 28s
- Warm Start: 28s
- Hot Start: 1.7s
- Sensitivity (@ Default Constellations):
- Acquisition: -146 dBm
- Tracking: -160 dBm
- Reacquisition: -155dBm
- Dynamic Performance:
- Maximum Altitude: 10000m
- Maximum Velocity: 490m/s
- Maximum Acceleration: 4g
- Update Rate:
- Default: 10Hz
- Max. 20Hz
- Supply Voltage Range: 3.15 - 3.45V, Typ. 3.3V
- I/O Voltage: Following VCC
Features & Specs
- Dimensions: 12.2 x 16 x 2.6mm
- Weight: Approx. 0.9g
- Operating Temperature: -40°C - +85°C
- Supported Bands:
- GPS: L1 C/A, L5, L2C
- GLONASS: L1, L2
- Galileo: E1, E5a, E5b, E6
- BDS: B1I, B1C, B2a, B2b, B2I, B3I
- QZSS: L1 C/A, L5, L2C
- NavIC: L5
- SBAS: L1
- Default Constellations: GPS + GLONASS + Galileo + BDS + QZSS + NavIC
- Number of Tracking Channels: 1040
- Number of Concurrent GNSS: 5 + QZSS
- Horizontal Position Accuracy:
- Autonomous: 0.7m
- RTK: 0.8cm + 1ppm
- Vertical Accuracy:
- Autonomous: 2.5m
-
- RTK: 1.5cm + 1ppm
- Velocity Accuracy (Without Aid): 0.03m/s
- Accuracy of 1PPS Sognal (RMS): 5ns
- RTK Convergence Time: 5s
- TTFF (without AGNSS):
- Cold Start: 28s
- Warm Start: 28s
- Hot Start: 1.7s
- Sensitivity (@ Default Constellations):
- Acquisition: -146 dBm
- Tracking: -160 dBm
- Reacquisition: -155dBm
- Dynamic Performance:
- Maximum Altitude: 10000m
- Maximum Velocity: 490m/s
- Maximum Acceleration: 4g
- Update Rate:
- Default: 10Hz
- Max. 20Hz
- Supply Voltage Range: 3.15 - 3.45V, Typ. 3.3V
- I/O Voltage: Following VCC
Documentation
WARNING: This product may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. See link below for more information. www.P65Warnings.ca.gov
Bulk Discount
| Quantity | Price |
| 2 | ₹ 15430.1 |
| 3-5 | ₹ 15272.65 |
| 5-10 | ₹ 14957.75 |
| 10+ | ₹ 14642.85 |
Bulk discount will be automatically applied during checkout based on quantity.
