Description
QNAP TS-H1886XU Overview
Significantly increase your business's storage capacity to support high-speed backups, data sharing, virtual machines, and more by integrating the versatile QNAP TS-h1886XU-RP R2 18-Bay NAS Enclosure into your network. Equipped with 12 front-facing 3.5" SATA III drive bays and six 2.5" rear bays, you can scale your data storage capacity as your needs grow. Installed drives can be configured for RAID 0, 1, 5, 6, 10, 50, 60, or Single modes to balance between performance and data redundancy. Powered by a 2.6 GHz Intel Xeon D-1622 quad-core processor with 32GB of DDR4 ECC memory, the TS-h1886XU-RP R2 is designed to provide fast data transfers that automatically detect and correct memory errors.
You can upgrade the system's memory and add expansion cards to the PCIe slots to further enhance performance. Connect this NAS to your network using the four 2.5G RJ45 Ethernet ports and the two 10G SFP+ fiber connectors. The TS-h1886XU-RP R2 uses the QuTS hero h5.0.0 operating system, which features ZFS file system support and is designed to ensure both data integrity and security.
QNAP TS-h1886XU-RP R2 NAS
10G & 2.5G Connectivity
Two 10G SFP+ fiber ports are available alongside four 2.5G RJ45 ports, providing high-speed connectivity to accelerate virtualization, intensive file access, and large backup/restoration tasks.
ECC Memory
This NAS enclosure includes 32GB of DDR4 ECC memory that can detect and correct single-bit memory errors. The TS-h1886XU-RP R2 supports up to 128GB of ECC memory, which can be installed across four long DIMM slots.
Upgrade Ready
With two PCIe 3.0 x4 slots, one of which hosts a preinstalled 10G SFP+ network card, and one PCIe 2.0 x4 slot, you can install an entry level graphics card, an M.2 SSD cache drive adapter, and more to expand the system's capabilities.
Redundant Power
The TS-h1886XU-RP R2 includes two 550W power supplies, which help to minimize downtime should one fail.
QuTS hero Operating System
Enhanced NAS Performance & Data Integrity
QuTS hero combines the app-based QTS with the 128-bit ZFS file system to provide flexible storage management, comprehensive data protection, and optimized performance to tackle the complexity and performance demands of modern IT. From storage management, virtualization, to collaborative media workflows, QuTS hero streamlines your business-critical tasks.
Inline Data Deduplication, Compression & Compaction
Advanced block-based data reduction technologies help to reduce file sizes, conserve storage capacity, and optimize performance. For example, if 20 virtual machines on a NAS are replicated using the same template, then storage space requirements for all 20 virtual machines can be reduced by up to 95%.
Hosting Virtual Machines & Containers
By running multiple virtual machines and containers on the TS-h1290FX, you can deploy multi-tenant environments and applications to increase management efficiency and save hardware costs. Coupled with the Network & Virtual Switch app that boosts interoperability between virtual machines, containers, QNAP NAS, and other physical devices on the network, you can flexibly allocate physical and virtual network resources to simplify network deployment.
Comprehensive Security
In addition to 256-bit AES volume encryption, this NAS includes flexible privilege settings and security measures. In addition to IP blocking, 2-step verification, and HTTPS connection, a variety of apps help ensure optimal protection against threats like malware and hackers.
UPC: 885022023592
In the Box
- QNAP TS-h1886XU-RP R2 18-Bay NAS Enclosure
- 2 x Power Cables
- Ethernet Cable
- 48 x Flat Head Screws for 3.5" HDDs
- 64 x Flat Head Screws for 2.5" HDDs
QNAP TS-H1886XU Specs
Computing
| CPU | 2.6 to 3.2 GHz Quad-Core |
| Processor | Intel Xeon D-1622 |
| Total Installed Memory | 32 GB ECC DDR4 |
| User-Replaceable Memory | 2 x 16 GB |
| Total Memory Slots | 4 x DIMM |
| Maximum Memory Capacity | 128 GB |
| Flash Memory | 5 GB |
General
| Number of Bays | 12 x 2.5"/3.5" 6 x 2.5" |
| I/O | 4 x RJ45 (2.5GbE) 2 x SFP+ (10GbE) 2 x USB Type-A (USB 3.1 / USB 3.2 Gen 1 (5 Gb/s)) |
| Compatible Drive Interface | SATA II, SATA III |
| Media Card Slots | None |
| Form Factor | Rackmount |
| RAID | RAID 0, 1, 10, 5, 50, 6, 60 |
| Hot-Swap Support | Yes |
| PCI Expansion | 1 x PCIe 2.0 x4 (x8 Electrical) 1 x PCIe 3.0 x4 1 x PCIe 3.0 x8 (x8 Electrical, Occupied) |
| Wake on LAN | Yes |
| Link Aggregation and Failover Support | Yes |
Networking
| Supported Protocols | AFP CIFS/SMB FTP FXP HTTP HTTPS IPv4 IPv6 L2TP/IPSec PPTP SFTP SNMP v2 SNMP v3 SSH TFTP Telnet |
| iSCSI Target | 256 |
| Max Concurrent Connections | 10,000 |
| Max Folders | 256 |
| Max Sync Tasks | 400 |
| Max Groups | 512 |
| Max User Accounts | 16,000 |
Software
| Installed Operating System | QuTS hero 5.0.0 |
| Supported File Systems | Internal: ZFS External: EXT3, EXT4, FAT32, HFS+, NTFS, exFAT |
| OS Compatibility | macOS 10.10 or Later Windows 7 or Later Windows Server 2008 R2 or Later Ubuntu 14.4 or Later CentOS 7 or Later Linux UNIX *As of April, 2022: Check with manufacturer for the most up-to-date compatibility |
| Supported Browsers | Chrome, Edge, Firefox, Safari |
Security
| Encryption | 256-Bit AES |
| VPN Client Connections | 100 |
Electrical
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Source | AC Adapter |
| Power Consumption | 117.92 W (Typical) |
| PSU Wattage | 2 x 550 W (Supports Redundancy) |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 5 to 95% |
| Storage Temperature | -4 to 158°F / -20 to 70°C |
Physical
| Status Monitoring | LED Indicator |
| Audible Alarm | Yes |
| Cooling | 3 x 60 mm Fans |
| Built-In Speakers | None |
| IR Sensor | None |
| Dimensions | 21.64 x 18.98 x 3.48" / 549.66 x 482.09 x 88.39 mm |
| Weight | 28.1 lb / 12.7 kg |
Packaging Info
| Package Weight | 40 lb |
| Box Dimensions (LxWxH) | 29 x 23.5 x 12" |
QNAP TS-H1886XU Reviews
