Description
QNAP TS-1232PXU Overview
- 1Description
- 2Performance
- 3Multi-Gig Connectivity
- 4Qtier Technology
- 5Hybrid Backup Sync
- 6Google Workspace and Microsoft 365 Backup
- 7USB Connectivity
- 8Redundant Power
Expand your small to medium sized business's network storage capacity for backups, team collaboration, and more with the TS-1232PXU-RP-4G 12-Bay NAS Enclosure from QNAP. Install up to twelve 2.5" / 3.5" SATA III drives into this 2 RU rackmount enclosure, which supports RAID 0, 1, 5, 6, 10, 50, 60, JBOD, and Single configurations to balance between security and performance. It can reach read speeds of up to 1946 MB/s and 643 MB/s write speeds over the dual 10 Gigabit SFP+ fiber line ports in RAID 5 mode. The two 2.5G RJ45 Ethernet ports can achieve 579 MB/s and 489 MB/s read and write speeds, respectively. Additionally, Qtier technology continually optimizes your data storage between installed solid-state and hard drives for efficient performance.
Boost performance further by installing a multi-Gig network card, an M.2 SSD cache adapter, or other compatible expansion into the PCIe 2.0 x2 slot. Additional features include link aggregation failover and load balancing support and hardware-based AES 256-bit encryption. Connect compatible peripherals such as external storage drives to the USB 3.2 Gen 1 Type-A ports to transfer data at up to 5 Gb/s. This NAS enclosure uses the QTS 4.4.3 operating system to manage its configuration, data, and supported applications.
Performance
Multi-Gig Connectivity
Qtier Technology
Hybrid Backup Sync
Google Workspace and Microsoft 365 Backup
USB Connectivity
Redundant Power
In the Box
- QNAP TS-1232PXU-RP-4G 12-Bay NAS Enclosure
- 2 x Power Cables
- Ethernet Cable
- 48 x Flat Head Screws for 3.5" Drives
- 36 x Flat Head Screws for 2.5" Drives
- Limited 3-Year Warranty
Not in the Box
- Essential Rack Accessories (Not Included)
- Description
- Performance
- Multi-Gig Connectivity
- Qtier Technology
- Hybrid Backup Sync
- Google Workspace and Microsoft 365 Backup
- USB Connectivity
- Redundant Power
QNAP TS-1232PXU Specs
| Total Installed Memory | 4 GB DDR4 |
| User-Replaceable Memory | 1 x 4 GB |
| Total Memory Slots | 1 x DIMM |
| Maximum Memory Capacity | 16 GB |
| Flash Memory | 512 MB |
| Number of Bays | 12 x 2.5"/3.5" |
| Connections | 2 x RJ45 (2.5GbE) 2 x SFP+ (10GbE) 4 x USB Type-A (USB 3.1 / USB 3.2 Gen 1 (5 Gb/s)) |
| Compatible Drive Interface | SATA II, SATA III |
| Media Card Slots | None |
| Form Factor | Rackmount (2 RU) |
| RAID Modes | RAID 0, 1, 10, 5, 50, 6, 60, JBOD, Single |
| Hot-Swap Support | Yes |
| PCI Expansion | 1 x PCIe 2.0 x2 |
| Wake on LAN | Yes |
| Link Aggregation and Failover Support | Yes |
| Supported Protocols | AFP CIFS/SMB FTP HTTP HTTPS IPv4 IPv6 L2TP/IPSec SFTP SNMP v2 SNMP v3 TFTP Telnet WebDAV iSCSI |
| iSCSI LUN | 256 |
| iSCSI Target | 256 |
| Max Concurrent Connections | 700 |
| Max Sync Tasks | 500 |
| Max Cameras Supported | 5000 |
| Installed Operating System | QTS 4.4.3 |
| Supported File Systems | Internal: EXT4 External: EXT3, EXT4, FAT32, HFS+, NTFS, exFAT |
| OS Compatibility | macOS 10.10 or Later Windows 7 or Later Windows Server 2008 R2 or Later Ubuntu 14.4 or Later CentOS 7 Linux UNIX |
| Supported Browsers | Chrome, Firefox, Safari |
| Encryption | 256-Bit AES |
| VPN Client Connections | 100 |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Source | AC Adapter |
| Power Consumption | 83.57 W (Typical) |
| PSU Wattage | 2 x 250 W (Supports Redundancy) |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 5 to 95% |
| Storage Temperature | -4 to 158°F / -20 to 70°C |
| Status Monitoring | LED Indicator |
| Audible Alarm | Yes |
| Cooling | 2 x 70 mm Fans |
| Noise Level | 32.2 dBA |
| Built-In Speakers | None |
| IR Sensor | None |
| Dimensions | 21.02 x 18.98 x 3.5" / 533.91 x 482.09 x 88.9 mm |
| Weight | 25.0 lb / 11.3 kg |
| Package Weight | 32.805 lb |
| Box Dimensions (LxWxH) | 28.1 x 21.9 x 10.3" |
