Description
QNAP QSW-M2108-2C Overview
Built with two 10GbE SFP+/RJ45 combo ports and eight 2.5GbE ports, the QSW-M2108-2C 10-Port 10GbE and 2.5GbE Managed Switch from QNAP lets you upgrade to 10GbE or 2.5GbE networking while optimizing bandwidth and ensuring secure network maintenance. It supports Layer 2 switching and network management via a user-friendly web interface and offers flexible deployment in hybrid high-speed network environments while providing an entry-level network management solution. Compatible with 10GbE and NBASE-T technologies that support 10GbE, 5GbE, 2.5GbE, 1GbE, and 100MbE, the QSW-M2108-2C provides higher transmission speeds with existing Cat 5e and 6a cables. An integrated fan helps keep things running cool, while IEEE 802.3az compliance helps reduce power usage and IEEE 802.3x Flow Control in full-duplex mode helps avoid packet loss. Additional features include plug-and-play functionality, port trunking, link aggregation, loop prevention, and more.
Please note that while there are two physical 10GbE SFP+ and two physical 10GbE RJ45 ports, for a total of four, one SFP+ and one RJ45 port are paired together as a combo port, meaning only one port in each pair may be used at a time.
General Features
Flexible Deployment with Multiple 10GbE SFP+ Fiber and Gigabit Ports
The QSW-M2108-2C provides two 10GbE SFP+/RJ45 combo ports and eight 2.5 Gigabit ports for connecting various devices and enabling hybrid high-speed networks. With SFP+ interfaces, Direct Attach Copper (DAC) cables can be used for connecting directly to SFP+ devices. You can also use RJ45 ports to connect 10GBASE-T/NBASE-T devices through RJ45 Category 6 (or better) cabling. The switching capacity of the QSW-M2108-2C is 80 Gb/s.
Note: 10GbE SFP+ ports are backward compatible with 1GbE SFP; the RJ45 (copper) combo port supports 10GbE, 5GbE, 2.5GbE, 1GbE, and 100MbE.
Note: 10GbE SFP+ ports are backward compatible with 1GbE SFP; the RJ45 (copper) combo port supports 10GbE, 5GbE, 2.5GbE, 1GbE, and 100MbE.
Flexible Deployment Combo Ports and 10GbE/NBASE-T
The QSW-M2108-2C is compatible with 10GbE and NBASE-T technologies to support five speeds (10GbE / 5GbE / 2.5GbE / 1GbE / 100MbE) using existing Cat 5e and Cat 6a cables. The SFP+/RJ45 (copper) combo ports provide higher transmission speeds with existing cables. Depending on cable type and lengths, different speeds can be achieved for faster, more efficient data transfer.
Note: If the distance between the switch and the device is less than 148 feet, a Cat 6 cable can be used to achieve 10 Gb/s speeds.
Note: If the distance between the switch and the device is less than 148 feet, a Cat 6 cable can be used to achieve 10 Gb/s speeds.
Embrace High-Speed Networking with QNAP
A Fast NAS
A QNAP NAS with multiple 2.5GbE ports and Port Trunking allows you to combine multiple ports for greater bandwidth potential.
Upgrade Desktops and Servers
Servers and desktops can install QNAP PCIe network cards that support 10GbE, 5GbE, 2.5GbE, 1GbE, and 100MbE Multi-Gig.
Add a 5GbE Port to Laptops
Laptops and upgrade-limited computers can use the portable QNAP USB 3.2 Gen 1 to 5GbE adapter that allows you to connect to 5GbE, 2.5GbE, 1GbE, and 100MbE networks via USB.
A QNAP NAS with multiple 2.5GbE ports and Port Trunking allows you to combine multiple ports for greater bandwidth potential.
Upgrade Desktops and Servers
Servers and desktops can install QNAP PCIe network cards that support 10GbE, 5GbE, 2.5GbE, 1GbE, and 100MbE Multi-Gig.
Add a 5GbE Port to Laptops
Laptops and upgrade-limited computers can use the portable QNAP USB 3.2 Gen 1 to 5GbE adapter that allows you to connect to 5GbE, 2.5GbE, 1GbE, and 100MbE networks via USB.
QSS: Intuitive Network Management Software
The QNAP Switch System (QSS) features an easy-to-use Web GUI with value-added functions to simplify network set up and management.
Sleek Design
Use the at-a-glance major functions, flat control layers, and one-click login to simplify set up and management.
GUI
The visual illustration matches physical ports for greater usability.
Value Added
With the settings guide, status chart reference, online firmware update, learning, and management costs are greatly reduced.
Sleek Design
Use the at-a-glance major functions, flat control layers, and one-click login to simplify set up and management.
GUI
The visual illustration matches physical ports for greater usability.
Value Added
With the settings guide, status chart reference, online firmware update, learning, and management costs are greatly reduced.
QSS: Human-Centered Settings Guide
QSS provides an overview dashboard, port management, and setting guide to help administrators control Layer 2 networks.
Overview Dashboard
View real-time system information, port connection status, and port traffic.
Port Management
View port status, port packet statistics, and configure port speeds.
Setting Guide
Quickly learn how to set up the networking using the introduction and step-by-step guide.
Exclusive Status Chart Referencing
Refer to four major status charts during each configuration to avoid going back and forth between different setting pages.
Online Firmware Check and Update
Keep your QSW-M2108-2C secure with one-click firmware updates.
Overview Dashboard
View real-time system information, port connection status, and port traffic.
Port Management
View port status, port packet statistics, and configure port speeds.
Setting Guide
Quickly learn how to set up the networking using the introduction and step-by-step guide.
Exclusive Status Chart Referencing
Refer to four major status charts during each configuration to avoid going back and forth between different setting pages.
Online Firmware Check and Update
Keep your QSW-M2108-2C secure with one-click firmware updates.
Optimize Network Performance with Bandwidth and Packet Control
The QSW-M2108-2C provides bandwidth and packet control functions (such as LACP, VLAN, QoS, and IGMP Snooping) to boost network performance through IP grouping and bandwidth management.
LACP
Link Aggregation (LAG) combines multiple network connections to increase throughput and protect against connection failure.
VLAN
Virtual Networks (VLAN) allow groups of devices from different networks to be combined into a single network.
QoS
QoS (Quality of Service) functions help prioritize bandwidth usage to optimize network resource allocation.
IGMP Snooping
IGMP snooping assists in minimizing bandwidth loss and preventing network information leakage.
LACP
Link Aggregation (LAG) combines multiple network connections to increase throughput and protect against connection failure.
VLAN
Virtual Networks (VLAN) allow groups of devices from different networks to be combined into a single network.
QoS
QoS (Quality of Service) functions help prioritize bandwidth usage to optimize network resource allocation.
IGMP Snooping
IGMP snooping assists in minimizing bandwidth loss and preventing network information leakage.
Powerful Security and System Functions
The QSW-M2108-2C has powerful security and system functions (including ACL, LLDP, RSTP, and Flow Control) to help administrators enhance network reliability using access controls, troubleshooting, loop prevention, and avoiding packet loss.
ACL
- Access controls
- System security
LLDP
- Device disclosure
- Troubleshooting
RSTP
- Loop prevention
- Backup path
Flow Control
- Balance speed
- Jam prevention
ACL
- Access controls
- System security
LLDP
- Device disclosure
- Troubleshooting
RSTP
- Loop prevention
- Backup path
Flow Control
- Balance speed
- Jam prevention
Desktop Form Factor for Office Use
With a compact and modern design, the QSW-M2108-2C stands out with its delicate textured surface design. The flexible DC power connector enables universal deployment of the QSW-M2108-2C and each port can be easily identified. Being fully plug-and-play, devices can be simply connected to the QSW-M2108-2C and immediately used.
RSTP
The QSW-M2108-2C is one of the few web-managed switches that supports Rapid Spanning Tree Protocol (RSTP). Easily and efficiently deploy small/medium-scale networks that support expansion, redundancy, and loop prevention.
IEEE 802.3az and 802.3x
Compliant with IEEE 802.3az Energy Efficient Ethernet and IEEE 802.3x Flow Control in full-duplex mode, the QSW-M2108-2C avoids packet loss from unparalleled bandwidth and reduces power consumption for low-speed and inactive connections.
UPC: 885022020386
In the Box
- QNAP QSW-M2108-2C 10-Port 10GbE and 2.5GbE Managed Switch
- Power Cord
- Power Adapter
- Limited 2-Year Warranty
QNAP QSW-M2108-2C Specs
Interfaces
| Ports | 2 x 10Gb Combo (Ethernet/SFP) 8 x 2.5 Gb/s Ethernet (RJ45) |
Protocols
| Supported Protocols | Link Aggregation |
| Jumbo Frames Support | 9000 Bytes |
| MAC Address Table Size | 16K |
Standards
| Supported IEEE Standards | 802.1ab, 802.1p, 802.1q, 802.1w, 802.3, 802.3ab, 802.3ad, 802.3ae, 802.3an, 802.3az, 802.3bz, 802.3u, 802.3x, 802.3z |
Performance
| Switching Bandwidth | 40 Gb/s (Non-Blocking) 80 Gb/s |
Electrical
| Power Draw | 12.17 W (Max) |
| DC Input Power | 12 VDC |
| Power Supply Type | External |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 5 to 95% |
| Certifications | BSMI, CE, CISPR 22 - Class B, FCC, VCCI, as per Manufacturer |
General
| Cooling System | Fan |
| Indicator Lights | Link/Activity/Speed, System/Power |
| Dimensions | 11.4 x 5 x 1.7" / 290 x 127 x 42.5 mm |
| Weight | 2.47 lb / 1.12 kg |
