Product details
Technical Specifications
Driver Type
General Purpose
External Width - Imperial
0.984"
Frequency Response Min
650Hz
Temperature Grade
High Temperature
External Depth - Metric
6.5mm
External Depth - Imperial
0.255"
External Width - Metric
25mm
Sound Pressure Level (SPL)
90dB
Product Dimensions
25mm x 25mm x 6.5mm
Frequency Range
650Hz to 20kHz
Frequency Response Max
20kHz
External Length - Metric
25mm
External Length - Imperial
0.984"
SVHC
No SVHC (21-Jan-2025)
Other details
| Brand |
PUI AUDIO |
| Part Number |
SMS-2504MS-WP-HT |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
