60-1-A-12/2 is a 60 series high voltage dry reed relay. It has got chassis mounting with solder connections on the top face. This reed relay is suitable for many applications such as high-end cable testers, backplane testers, big physics and high voltage instrumentation.
- Tungsten plated contacts ensure a long and reliable life
- Coil voltage is 12V, coil resistance is 150 ohm
- Maximum contact resistance is 0.15 ohm
- Power rating is 50W, maximum switch current is 3A
- Maximum carry current is 3.5A
- Maximum switching voltage is 7500VDC, maximum stand-off voltage is 10000VDC
- Life expectancy is 10�
- Life expectancy is 10�
Footnotes High voltages, and stray capacitance can generate very high current pulses, which can damage the contact plating causing welding of the reed switch.
Other details
| Brand |
PICKERING |
| Part Number |
60-1-A-12/2 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
