112-1-A-12/2D is a 112 series general purpose single-in-line SIL/SIP reed relay. It is a highest quality sputtered ruthenium instrumentation grade reed switch. It has plastic package with internal mu-metal magnetic screen the internal mu-metal screen totally eliminates the risk of magnetic interaction problems.
- Ideal for high density card based systems and automatic test equipment
- Take up the minimum of board area, conserving board space
- 100% tested for dynamic contact resistance
- Fast operate times with minimal contact bounce result in less electrical noise
- Coil voltage is 12V, coil resistance is 750 ohm
- Maximum contact resistance is 0.12 ohm
- Maximum operating voltage is 9V, minimum operating voltage is 1.2V
- 1 Form A configuration, comes with internal diode
- Maximum switch current is 0.5A, maximum switching volts is 200V
- Power rating is 10W, life expectancy is 10�, operating temperature range is -20°C to +85°C
Other details
| Brand |
PICKERING |
| Part Number |
112-1-A-12/2D |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
