Description
The PC 4/12-STF-7,62 from Phoenix Contact is a 12 position pluggable terminal block with screw connection, tension sleeve. This terminal block comes with 7.62mm pitch spacing and suitable for wire size ranging from 24AWG to 10AWG.
- Green colour insulation
- Tin contact surface, PA insulating material
- 20A nominal current, 630V rated voltage (III/2)
- Flammability rating according to UL94 V0
- Well-known connection principle allows worldwide use
- Maximum contact force, allows connection of two conductors
- Integrated double steel spring provide additional safety in event of temperature, power fluctuations
- Screwable flange for superior mechanical stability
- CSA, UL, cUL, LR, BV, EAC, DNV GL, cULus recognized
- Dimension of terminal block is 30.7mm x 106.66mm x 18.1mm (L x W x H)
Industrial
Other details
| Brand | PHOENIX CONTACT |
| Part Number | PC 4/12-STF-7,62 |
| Quantity | Each |
| Technical Data Sheet EN |  |
