Description
The MSTB 2,5/16-STF-5,08 from Phoenix Contact is a 5.08 pitch, COMBICON plug-in PCB connector with 16 position. The plug-in direction parallel to the conductor axis with screw flange and suitable for wire gauge range from 24AWG to 12AWG.
- Nominal current is 12A
- Rated voltage (III/3) is 250V, (III/2) is 320V, (II/2) is 630V
- Green colour polyamide insulating material
- Connection capacity is 0.2mm² to 2.5mm² (solid), 0.2mm² to 2.5mm² (stranded)
- Flammability rating according to UL 94 V0
- Screwable flange for superior mechanical stability
- Contract surface is tin
Industrial
Other details
| Brand | PHOENIX CONTACT |
| Part Number | MSTB 2,5/16-STF-5,08 |
| Quantity | Each |
| Technical Data Sheet EN |  |
