Description
The MSTB 2,5/12-ST-5,08 is a 12-position green pluggable PCB Terminal Block with tin-plated solder contacts, a polyamide insulator and the M3 screw connection. This 1757116 terminal block provides individual position coding by inserting coding profiles. It accepts 24 to 12AWG wire range.
- Green colour insulation
- Tin contact surface
- Plug-in direction parallel to the conductor axis
- Individual position coding by inserting coding profiles
- Polyamide (PA) insulating material
- UL94 V-0 flammability rating
- CSA, VDE, IECEE CB, CCA, EAC and cULus recognized
- Dimension of terminal block is 18.3mm x 15mm x 60.96mm (L x H x W)
- 7mm Stripping length
Industrial
Other details
| Brand | PHOENIX CONTACT |
| Part Number | MSTB 2,5/12-ST-5,08 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
| CAD Multiple Formats EN | |
| Drawing EN | |
