Description
The MC 1,5/16-ST-3,81 from Phoenix Contact is a 3.81mm pitch, 16 pole pluggable terminal block. The plug-in direction parallel to the conductor axis with wire size ranging from 28AWG to 16AWG.
- Nominal current is 8A
- Rated voltage (III/3) is 250V, (III/2) is 320V, (II/2) is 400V
- Rated surge voltage (III/3) is 4KV, (III/2) is 4KV, (II/2) is 4KV
- Green colour polyamide insulating material, flammability rating according to UL94 V0
- Nominal cross section is 1.5mm²
- Contact surface is tin
- Stripping length is 7mm
- CSA, VDE, CCA, cULus standards
- Screw connection with tension sleeve
Industrial
Other details
| Brand | PHOENIX CONTACT |
| Part Number | MC 1,5/16-ST-3,81 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 2125.86 |
| 3-5 | ₹ 2104.16 |
| 5-10 | ₹ 2060.78 |
| 10+ | ₹ 2017.39 |
Bulk discount will be automatically applied during checkout based on quantity.
