Description
The 1827185 is a 8-way Printed Circuit Board Connector with tin-plated contacts. The MCVR 1,5/ 8-ST-3,81 pluggable terminal block comes with a PA insulator and provides flexible connection.
- Generously dimensioned wiring space
- Compact dimensions of the MCV 1,5 plug range
- Plug-in direction vertical to the conductor axis
- UL94V-0 Flammability rating
Applications
Industrial
Product details
| Pitch Spacing: 3.81mm |
| No. of Positions: 8Ways |
| Wire Size (AWG): 28AWG to 16AWG |
| Conductor Area CSA: 1.5mm² |
| Wire Connection Method: Screw |
| Rated Current: 8A |
| Rated Voltage: 160V |
| Product Range: MCVR |
Other details
| Brand | PHOENIX CONTACT |
| Part Number | 1827185 |
| Quantity | Each |
| Technical Data Sheet EN |  |
