Description
The 1757077 is a 8-position 5.08mm printed-circuit board connector Terminal Block with PA (polyamide) insulator, 2.5mm² conductor area and screw wire connection method, 24 to 12AWG wire size and M3 screw thread.
- UL94V-0 Flammability rating
- 7mm Stripping length
- Tin-plated contacts
- Green colour
- Plug-in direction parallel to conductor axis
- Individual position coding by inserting coding profiles
Applications
Industrial
Footnotes
CR-MSTB may only be used after reflow soldering. CR-MSTB NAT HT may also be used prior to reflow soldering.
Product details
| Pitch Spacing: 5.08mm |
| No. of Positions: 8Ways |
| Wire Size (AWG): 24AWG to 12AWG |
| Conductor Area CSA: 2.5mm² |
| Wire Connection Method: Screw |
| Rated Current: 12A |
| Rated Voltage: 320V |
| Product Range: MSTB |
Other details
| Brand | PHOENIX CONTACT |
| Part Number | 1757077 |
| Quantity | Each |
| Technical Data Sheet EN |  |
