Description
The 1727081 is a 9-position 13.5A green wire-to-board Terminal Block with tin-plated contact surface and a polyamide insulator. The MKDS 1/ 9-3,81 terminal block has screw connection with tension sleeve and 0° conductor/PCB connection direction.
- UL94V-0 Flammability rating
- M2 Screw thread size
- Single-row type with horizontal connection direction
Applications
Industrial
Product details
| Pitch Spacing: 3.81mm |
| No. of Positions: 9Ways |
| Wire Size AWG Min: 26AWG |
| Wire Size AWG Max: 16AWG |
| Conductor Area CSA: 1.5mm² |
| Wire Connection Method: Screw |
| Rated Current: 10A |
| Rated Voltage: 300V |
| Block Orientation: Through Hole Right Angle |
| Product Range: MKDS1 |
Other details
| Brand | PHOENIX CONTACT |
| Part Number | 1727081 |
| Quantity | Each |
| Technical Data Sheet EN |  |
