Product details
Inductance |
47µH |
RMS Current (Irms) |
2.2A |
Inductor Construction |
Shielded |
Saturation Current (Isat) |
3.7A |
Product Range |
PCC-M0748M-LE Series |
Power Inductor Case |
7.4mm x 7mm x 4.8mm |
DC Resistance Max |
0.1635ohm |
Inductance Tolerance |
± 20% |
RoHS Phthalates Compliant |
To Be Advised |
Other details
Brand |
PANASONIC |
Part Number |
ETQP4M470KFM |
Quantity |
Each (Supplied on Cut Tape) |
Technical Data Sheet EN |
|
