This is a SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 390 µF, 50 V, FK Series, 5000 hours @ 105°C product from PANASONIC ELECTRONIC COMPONENTS with the model number EEVFK1H391Q
Product details
| AE Capacitor Case |
Radial Can - SMD |
| Capacitance |
390µF |
| Voltage Rating |
50V |
| ESR |
- |
| Product Range |
FK Series |
| Lifetime @ Temperature |
5000 hours @ 105°C |
| Operating Temperature Min |
-55°C |
| Operating Temperature Max |
105°C |
| Ripple Current AC |
900mA |
| Diameter |
12.5mm |
| Height |
13.5mm |
| Automotive Qualification Standard |
AEC-Q200 |
| RoHS Phthalates Compliant |
To Be Advised |
| MSL |
- |
Other details
| Brand |
PANASONIC ELECTRONIC COMPONENTS |
| Part Number |
EEVFK1H391Q |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
| Product Change Notice EN |
|
