The Panasonic EEUFC series capacitors are automotive grade, surface mount polarized aluminium electrolytic capacitors. The capacitance value ranges from 1?F to 1500?F. These capacitors are solution for low impedance solutions.
- High reliability
- Low impedance
- Automotive grade AEC-Q200 compliant
- Tolerance of ?20%
- Endurance of 1000h to 5000h at 105?C
- Operating temperature range -55?C to 105?C
- Rated voltage range of 6.3VDC to 100VDC
Product details
| Capacitance |
56?F |
| Voltage Rating |
63V |
| Product Range |
EEUFC Series |
| Capacitance Tolerance |
? 20% |
| Capacitor Terminals |
Radial Leaded |
| Diameter |
8mm |
| Lead Spacing |
3.5mm |
| Height |
11.5mm |
| Operating Temperature Min |
-55?C |
| Operating Temperature Max |
105?C |
| Lifetime @ Temperature |
2000 hours @ 105?C |
| ESR |
- |
| Automotive Qualification Standard |
AEC-Q200 |
Other details
| Brand |
PANASONIC |
| Part Number |
EEUFC1J560 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
| CAD CadSoft_EAGLE EN |
|
| Product Change Notice EN |
|
