Description
The EEEFPC221XAP is a FP series type V surface mount polarized Aluminium Electrolytic Capacitor suitable for high temperature lead-free reflow. This capacitor is perfect solution for applications which require ultra low ESR, very high ripple current and very long life.
- 3µA (after 2 minutes) DC leakage current
- 600mA RMS at 100kHz/+105°C Rated ripple current
- Rated voltage range from 6.3VDC to 50VDC
- ±20% tolerance
- Endurance is 2000h at 105°C
- Operating temperature range -55°C to 105°C
Multimedia, Consumer Electronics, Industrial, Communications & Networking, Portable Devices, Automotive
Other details
| Brand | PANASONIC |
| Part Number | EEEFPC221XAP |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| CAD Multiple Formats EN | |
| Product Change Notice EN | |
| CAD CadSoft_EAGLE EN | |
