S series V Type aluminium electrolytic capacitors are characterized by their endurance of 85°C 2000h.
- AEC-Q200 qualified
- Temperature range from -40°C to +85°C
Product details
| Capacitor Case / Package:
Radial Can - SMD
|
| Capacitance:
22µF
|
| Voltage(DC):
100V
|
| ESR:
-
|
| Lifetime @ Temperature:
2000 hours @ 85°C
|
| Polarity:
Polar
|
| Product Range:
S
|
| Capacitance Tolerance:
± 20%
|
| Capacitor Terminals:
Solder
|
| Product Diameter:
8mm
|
| Product Length:
-
|
| Product Width:
-
|
| Product Height:
10.2mm
|
| Ripple Current:
55mA
|
| Operating Temperature Min:
-40°C
|
| Operating Temperature Max:
85°C
|
| Qualification:
AEC-Q200
|
| MSL:
-
|
Other details
| Brand |
PANASONIC |
| Part Number |
EEE2AA220UP |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
