ECQUA series (Class X2) metallized polypropylene film capacitor for automotive applications.
- High safety (safety function installed)
- High humidity resistance (85°C, 85%)
- High thermal shock resistance (-40 to 85°C, 1000 cycles)
- Flame-retardant plastic case and non-combustible resin
- AEC-Q200 compliant
- Interference suppressors for automotive applications
- In accordance with UL/CSA and European safety regulation class X2 equipped with a safety mechanism
Product details
| Dielectric Type:
Metallized PP
|
| Capacitor Case / Package:
Radial Box - 2 Pin
|
| Capacitance:
0.22µF
|
| Capacitance Tolerance:
± 10%
|
| Suppression Class:
X2
|
| Capacitor Mounting:
Through Hole
|
| Voltage Rating X:
275VAC
|
| Voltage Rating Y:
-
|
| dv/dt Rating:
-
|
| Humidity Rating:
GRADE III (Test Condition B)
|
| Lead Spacing:
15mm
|
| Operating Temperature Min:
-40°C
|
| Operating Temperature Max:
110°C
|
| Product Range:
ECQUA
|
| Qualification:
AEC-Q200
|
Other details
| Brand |
PANASONIC |
| Part Number |
ECQUAAF224T1 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
