Description
Product Overview
ALQ6F12 is a LQ series power relay.
- Sealed protective construction, single side stable operating function, PC board terminal shape
- Slim relay shape, inrush contact rating, Class F insulation coil insulation class
- 12VDC rated coil voltage, 16.7mA rated operating current
- 720 ohm coil resistance, 200mW rated operating power
- 1 Form A contact arrangement, single contact shape
- AgSnO2 type (movable)/AgNi type (stationary) contact material
- 10A 125V AC, 8A 250V AC, 5A 30V DC contact rating (resistive load)
- 2,000VA, 150W maximum switching power (resistive load)
- 10A (125V AC), 5A (30V DC) max switching current
- Ambient temperature range from -40°C to +85°C
Product details
Other details
| Brand | PANASONIC |
| Part Number | ALQ6F12 |
| Quantity | Each |
| Technical Data Sheet EN |  |
