Description
Panamax MB1500 Overview
- 1Description
- 2AVM Automatic Overvoltage & Undervoltage Protection
- 3LiFT Linear Noise Filtration Technology
- 4Automation Communication Interface
- 5External Battery Connectors
The MB1500 Rackmount UPS from Panamax combines power management, voltage regulation, and surge protection with automatic voltage monitoring and battery backup to provide a complete power solution for your audio, video, and computer equipment. With voltage regulation and monitoring, the MB1500 keeps power running clean and even, reducing added noise and distortion to your audio and video gear. In the event of a surge greater than the capacity of the surge protection components, the MB1500's protect or disconnect circuitry will disconnect your equipment in order to protect it. The MB1500 will prevent critical equipment from stored data and hard-disk crashes, and from losing setup configuration. Especially good for equipment such as projectors, the MB1500 can shut off equipment via IR control to allow projector bulbs to go through a proper cool-down cycle before shutting off.
The MB1500 will withstand, without damage, 10,000A surges, far exceeding the UL requirement of only 3000 Ampere surges.
BlueBOLT Compatibility (with BlueBOLT-CV1 interface card, sold separately) provides remote access to reboot components, power equipment on or off, and monitor power quality from anywhere in the world.
In the Box
- Panamax MB1500 Rackmount UPS, Voltage Regulator & Power Conditioner
- DB-9 Serial Cable
- Front Rack Mount Ears
- Software CD
- USB Cord
- Limited 3-Year Manufacturer Warranty (On Uninterruptible Power Supply)
- Limited 2-Year Manufacturer Warranty (On Batteries)
- Description
- AVM Automatic Overvoltage & Undervoltage Protection
- LiFT Linear Noise Filtration Technology
- Automation Communication Interface
- External Battery Connectors
Panamax MB1500 Specs
| Form Factor | Rackmount (with Optional Hardware) |
| Type | Conditioner |
| Rated Current | 12 A |
| Number of Circuits | Not Specified by Manufacturer |
| Metering | None |
| Battery Backup | Yes |
| Typical Backup Runtime | 12 Minutes (Full-Load) 30 Minutes (Half-Load) |
| Integrated Lamps | None |
| Outlets | 8 |
| AC Power I/O | Hardwired |
| USB Ports | 1 x USB-B |
| Ethernet | None |
| Coaxial | None |
| RJ11 | None |
| Remote | 1 x DE-9/DB-9 (RS-232) |
| Lamp I/O | None |
| Bluetooth | None |
| Wireless | None |
| Mobile App Compatible | No *As of May, 2023: Check with manufacturer for the most up-to-date compatibility |
| AC Input Power | 90 to 140 VAC, 50 / 60 Hz |
| Output Voltage | 120 VAC, 60 Hz |
| Load Capacity | Not Specified by Manufacturer |
| Sequencing Delay | None |
| Protection Types & Modes | Overvoltage, Undervoltage, Auto-Reset |
| Circuit Breaker | Yes |
| Undervoltage Protection | 90 V ± 5 V |
| Overvoltage Protection | 150 V ± 5 V |
| Transformer Isolated | No |
| EMI/RFI Noise Filtration | 10 dB (10 kHz) 40 dB (100 kHz) 50 dB (500 kHz) |
| Rackmount Size | 2 RU (with Optional Hardware) |
| Cable Management | None |
| Dimensions | 19.2 x 17 x 3.5" / 48.8 x 43.2 x 8.9 cm |
| Weight | 72 lb / 32.7 kg |
