The Osram OPTOTRONIC NFC series LED driver has a constant current and provides great flexibility due to the wide operating temperature range of -40°C to 55°C or 60°C. The all-in-one solution for your Outdoor application. Some highlights of this robust LED driver are an easy and fast luminaire programming via NFC and a 4DIM functionality consisting of StepDIM, AstroDIM, MainsDIM and DALI-2. Additionally a customizable thermal management (Driver Guard) is also integrated and the surge protection goes up to 10 kV.
- Supply voltage range from 220V to 240V
- Current output range: 70-1050mA
- Easy and fast wireless luminaire programming via NFC
- Flexible current setting with one additional wire (LEDset2)
- AstroDIM for autonomous dimming with five independent levels (astro, time mode)
- Allows for energy saving in twilight phases
- MainsDIM function for dimming via reduction of line voltage amplitude
- Isolated DALI interface for bidirectional tele management
- Standby power consumption of < 0.35W
- Constant lumen output (CLO)
Product details
| Power Supply Applications:
LED Lighting
|
| Output Power Max:
110W
|
| Output Voltage Max:
220V
|
| Output Current:
1.05A
|
| LED Driver Mode:
Constant Current
|
| Input Voltage Min:
170V
|
| Input Voltage Max:
264V
|
| Product Range:
OPTOTRONIC - 4DIM NFC IP20 Series
|
Other details
| Brand |
OSRAM |
| Part Number |
OT-110/170-240/1A0-4DIMLT2G2CE |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
