The Osram ICUTRONIC Compact family are a range of constant current LED drivers. The small housing is ideal for flexible luminaire designs. Each driver is fitted with DIP switches allowing for multi-current selection. Reversible overtemperature, overload, short-circuit and open-circuit protection. With integrated cable clamps for cable management.
- Supply voltage range from 220V to 240V
- Line frequency: 50Hz, 60Hz
- Line voltage: 198-264V
- According to EN 61347-1, 61347-2-13, 62384
- RI suppression according to CISPR 15
- Line harmonics according to IEC 61000-3-2
- Immunity according to IEC 61547
- Small housing for flexible luminaire designs
- Flexible current selection via DIP switch
- Reversible overtemperature, overload, short-circuit and open-circuit protection
Product details
| Power Supply Applications:
LED Lighting
|
| Output Power Max:
10.5W
|
| Output Voltage Max:
21V
|
| Output Current:
500mA
|
| LED Driver Mode:
Constant Current
|
| Input Voltage Min:
198V
|
| Input Voltage Max:
264V
|
| Product Range:
ICUTRONIC FIT CS I Series
|
Other details
| Brand |
OSRAM |
| Part Number |
IT-FIT-11/220-240/500-CS-I |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
