Description
OSEE GoStream Deck Overview
- 1Description
- 2
- 3
- 4Streamline Your Livestream Production
- 5Supports Three Simultaneous Streams
- 6Versatile Interface
- 7Built-In Audio Mixer
- 8Unified Video Integration
- 96-Layer Composition Engine, Macro Presets
- 10
By Photo's
Jordan Gallant
Facilitate engaging livestreams with a portable gear configuration using the
OSEE GoStream Deck Video Switcher thanks to its HDMI/USB connections compatible with portable monitors and livestreaming cameras. The switcher features four HDMI inputs and one USB-C input that interface with two HDMI outputs and one USB-C output. Both the input and output ports support up to 1080p60 video. An SD card slot allows for direct recording and playback to a connected monitor without requiring a separate PC. Stream via RTMP and Ethernet connection to up to three social media platforms.
Streamline Your Livestream Production
The GoStream Deck's comprehensive control panel, built-in user interface, and SD card recording and playback function reduces the number of required devices needed to facilitate your livestream. This keeps your production low cost and efficient.
Supports Three Simultaneous Streams
Livestream to three different platforms simultaneously using the integrated Ethernet port on the GoStream. Connect a USB webcam to the USB-C input and output that feed via OBS, VMix, or Zoom using the USB-C output port.
Versatile Interface
Additional ports on the switcher allow you to expand your setup to best suit your production. Connect up to five video input sources like cameras and UVC sources and output them to a monitor or projector for simultaneous presentation.
Built-In Audio Mixer
An internal audio mixer supports seven channels of embedded and input audio sources, with four audio sources coming from the HDMI inputs, one from the AUX input, and two from dedicated 3.5mm TRS microphone ports. Mix the inputs into the program output using the On/Off or AFV controls on the switcher and adjust parameters like gain, balance, and fade. Monitor audio from a selected source using the headphone input.
Unified Video Integration
Using the Super Source feature, merge two video windows and one background video into a unified single source. The source then becomes a standard video input integrated into the composition engine. Select source material from video inputs or internally generated still image signals. Modify the layout, size, position, and border of each window.
6-Layer Composition Engine, Macro Presets
The GoStream supports six layers of special effects including Super Source, upstream keyers, downstream keyers, Chroma keyers, transitions, and a still image generator. Craft visually appealing, multi-layered effects tailored to your production. Use the eight Macro Memories to record specific composition functions and set them as custom presets for efficient recall.
In the Box
- OSEE GoStream Deck HDMI/USB Live Streaming Video Switcher
- Power Adapter
- Limited 1-Year Manufacturer Warranty
Table of Contents
- Description
- Streamline Your Livestream Production
- Supports Three Simultaneous Streams
- Versatile Interface
- Built-In Audio Mixer
- Unified Video Integration
- 6-Layer Composition Engine, Macro Presets
OSEE GoStream Deck Specs
| Available M/E Layers |
6 M/E
|
| Effect Types |
Transition, Chroma Key, Luma Key
|
| Downstream Keys |
1 x Chroma, Luma
|
| Generators |
5 x Color
2 x Pattern |
| Audio Mixing |
7-Channel Mixing
|
Processing
| Switching Type |
Pushbutton, Software
|
| Color Processing |
12-Bit 4:2:2 YCbCr
8-Bit 4:4:4 RGB |
Input
| Number of Video Input Sources |
5
|
| Video Inputs |
4x HDMI
1x USB-C (UVC) |
| Input Video Format |
HDMI (8/12-Bit 4:4:4/4:2:2 RGB, YCC)
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps |
| Audio Inputs |
2x 1/8" / 3.5 mm TRS Mic
|
| Input Audio Format |
Analog
|
| Embedded Audio Input |
HDMI
|
Output
| Video Output Channels |
3
|
| Video Outputs |
2x HDMI
1x USB-C |
| Output Video Format |
HDMI (8/12-Bit 4:4:4/4:2:2 RGB, YCC)
1080p at 24/25/30/50/60 fps |
| Audio Outputs |
1x 1/8" / 3.5 mm TRS Stereo
|
| Embedded Audio Output |
HDMI
|
| Multiview Output |
4-Way Multiview via HDMI
|
Connectivity
| Other I/O |
1x RJ45 LAN Input/Output
|
| IP Video |
1920 x 1080 at 24p, 25p, 30p, 50p, 60p Encoding
|
| Transport Protocols |
RTMP
|
| Simultaneous Streams |
3 Streams
|
| Recording Media |
1 x SD (Unspecified Type)
|
| Recording Modes |
1920 x 1080p at 24/25/30/50/60 fps (70 Mb/s H.264/AVC)
|
Hardware
| Processor |
Not Specified by Manufacturer
|
| Wi-Fi |
Yes
|
| Bluetooth |
No
|
| Power Consumption |
Device: 12 VDC (12 W)
|
Environmental
| Operating Temperature |
32 to 158°F / 0 to 70°C
|
| Operating Humidity |
10 to 90% ()
|
General
| Dimensions |
9.9 x 4.2 x 1.9" / 252.4 x 107.3 x 49.3 mm
|
| Weight |
1.1 lb / 0.5 kg
|
Packaging Info
| Package Weight |
2.515 lb
|
| Box Dimensions (LxWxH) |
12.6 x 6 x 3.9"
|
