Description
The OpenMV Cam is a small, low power, microcontroller board which allows you to easily implement applications using machine vision in the real-world.
Features & Specs
- Processor:
- ARM® 32-bit Cortex®-M7 CPU w/ Double Precision FPU
- 600 MHz (1284 DMIPS)
- Core Mark Score: 3020 (compare w/ Raspberry Pi 3: 3800)
- RAM Layout (33MB Total):
- 32KB Stack
- 480KB .DATA/.BSS/Heap/DMA
- 32MB Frame Buffer/Stack
- 512KB SDRAM Cache
- Flash Layout (16MB Total):
- 256KB Bootloader
- 3.768MB Firmware
- 4MB Embedded Flash Drive
- 8MB Reserved
- Supported Image Formats:
- Grayscale
- RGB565
- JPEG (and BAYER/YUV422)
- Maximum Supported Resolutions:
- Grayscale: 2952x1944 (5MP) and under
- RGB565: 2952x1944 (5MP) and under
- Grayscale JPEG: 2952x1944 (5MP) and under
- RGB565 JPEG: 2952x1944 (5MP) and under
- Lens Info:
- Focal Length: 2.8mm
- Aperture: F2.0
- Format: 1/3"
- HFOV = 70.8°, VFOV = 55.6°
- Mount: M12*0.5
- IR Cut Filter: 650nm (removable)
- All pins are 3.3V Tolerant with a 3.3V Output
- Power Consumption
- Idle: 100mA @ 5V
- Active: 130mA @ 5V
Features & Specs
- Processor:
- ARM® 32-bit Cortex®-M7 CPU w/ Double Precision FPU
- 600 MHz (1284 DMIPS)
- Core Mark Score: 3020 (compare w/ Raspberry Pi 3: 3800)
- RAM Layout (33MB Total):
- 32KB Stack
- 480KB .DATA/.BSS/Heap/DMA
- 32MB Frame Buffer/Stack
- 512KB SDRAM Cache
- Flash Layout (16MB Total):
- 256KB Bootloader
- 3.768MB Firmware
- 4MB Embedded Flash Drive
- 8MB Reserved
- Supported Image Formats:
- Grayscale
- RGB565
- JPEG (and BAYER/YUV422)
- Maximum Supported Resolutions:
- Grayscale: 2952x1944 (5MP) and under
- RGB565: 2952x1944 (5MP) and under
- Grayscale JPEG: 2952x1944 (5MP) and under
- RGB565 JPEG: 2952x1944 (5MP) and under
- Lens Info:
- Focal Length: 2.8mm
- Aperture: F2.0
- Format: 1/3"
- HFOV = 70.8°, VFOV = 55.6°
- Mount: M12*0.5
- IR Cut Filter: 650nm (removable)
- All pins are 3.3V Tolerant with a 3.3V Output
- Power Consumption
- Idle: 100mA @ 5V
- Active: 130mA @ 5V
Documentation
WARNING: This product may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. See link below for more information. www.P65Warnings.ca.gov
Bulk Discount
| Quantity | Price |
| 2 | ₹ 23598.4 |
| 3-5 | ₹ 23357.6 |
| 5-10 | ₹ 22876.0 |
| 10+ | ₹ 22394.4 |
Bulk discount will be automatically applied during checkout based on quantity.
