NCP1117I series are low dropout (LDO) positive linear voltage regulators that are capable of providing an output current that is in excess of 1.0A with a maximum dropout voltage of 1.2V at 800mA over temperature. This series contains eight fixed output voltages of 1.8 V, 3.3 V and 5.0 V that have no minimum load requirement to maintain regulation. Also included is an adjustable output version that can be programmed from 1.25 V to 18.8 V with two external resistors. On chip trimming adjusts the reference/output voltage to within +/- 1.0% accuracy. Internal protection features consist of output current limiting, safe operating area compensation and thermal shutdown. The NCP1117I series can operate with up to 20 V input. Devices are available in SOT223 and DPAK packages.
- Operation to 20V input
- Fixed output voltage
- Current limit, safe operating and thermal shutdown protection
- On chip trimming adjusts the reference/output voltage to within +/- 1.0% accuracy
Product details
| Output Type:
Fixed
|
| Input Voltage Min:
2.4V
|
| Input Voltage Max:
20V
|
| No. of Outputs:
1Outputs
|
| Output Voltage Nom:
1.8V
|
| Output Voltage Min:
-
|
| Output Voltage Max:
-
|
| Polarity:
Positive Output
|
| Output Current Max:
1A
|
| Dropout Voltage Typ @ Current:
1.07V
|
| IC Mounting:
Surface Mount
|
| IC Case / Package:
SOT-223
|
| No. of Pins:
3Pins
|
| Operating Temperature Min:
-40°C
|
| Operating Temperature Max:
125°C
|
| Product Range:
1.8V 1A LDO Voltage Regulators
|
| MSL:
MSL 1 - Unlimited
|
Other details
| Brand |
ONSEMI |
| Part Number |
NCP1117IST18T3G |
| Quantity |
|
| Technical Data Sheet EN |
 |
