Description
The H7EC-NV-BH is a flush-mount Self-powered Tachometer with PNP/NPN universal DC voltage input and 7-segment LCD with backlight display. It has 100MR minimum (at 500VDC) between current-carrying metal parts and exposed non-current carrying metal parts and between the backlight power supply terminal and count input terminals/reset terminals for backlight model insulation resistance and 4.5kV between current-carrying terminal and exposed non-current-carrying metal parts impulse withstand voltage. It is a subminiature total counter with improved appearance.
- Key-protect switch to prevent front resetting
- Replaceable battery
- New black case
- Screw terminals
- NEMA-4/IP66 front
- Eight-digits, counting range 0 to 99999999
Applications
Automation & Process Control
Warnings
An insulation sheet has been inserted to maintain the quality of the Totalizer in the event of a long period without use. Be sure to remove this sheet before attempting to use the product.
Product details
| Supply Voltage Max | 24VDC |
| Panel Cutout Height | 22.2mm |
| Panel Cutout Width | 45mm |
| No. of Digits / Alpha | 8 |
| Operating Temperature Min | -10°C |
| Product Range | - |
| Supply Voltage Min | - |
| Digit Height | 8.6mm |
| Operating Temperature Max | 55°C |
Other details
| Brand | OMRON INDUSTRIAL AUTOMATION |
| Part Number | H7EC-NV-BH |
| Quantity | Each |
| Technical Data Sheet EN |  |
