Description
Obsidian EN6 IP Overview
IP66 rated to suit live productions, movie sets, and both outdoor and indoor installations, the EN6 IP Art-Net/sACN to DMX Node from Elation Professional offers six 5-pin DMX/RDM optically isolated bidirectional ports and two locking IP66 RJ45 Ethernet network connections for compatibility with RDM, Art-Net, and sACN protocols. All these features are built into an IP66 powder-coated aluminum chassis that suits temporary outdoor installations, as well as interior spaces that still require protection from humidity, dust, and debris.
- 99 internal cues with fade and delay time
- 6W power
- Ports are bidirectional for DMX in and out
- Locking IP66 power in/thru
- Unlocks ONYX NOVA 4-universe license
- Note: the EN6 IP has unlocked four universes, but can be updated to run up to six universes
- Obsidian EN6 IP Art-Net/sACN to DMX Node
- IP66 Locking Power Cable (4.9')
- 2 x Wall Mount Bracket
- M10 to M12 Adapter
- Metal Display Protection Cover
- Limited 2-Year Manufacturer Warranty
Obsidian EN6 IP Specs
| Inputs/Outputs |
6x XLR 5-Pin (DMX) Female Input/Output
2x RJ45 Locking Female |
| Power Source |
AC Power, Power Over Ethernet (PoE)
|
| Protocol |
ArtNet, RDM, sACN
|
| Inputs/Outputs |
6x XLR 5-Pin (DMX) Female Input/Output
2x RJ45 Locking Female |
| Power Source |
AC Power, Power Over Ethernet (PoE)
|
| Power Consumption |
6 W
|
| Input Power |
100 to 240 VAC, 50 / 60 Hz
|
| PoE Port Power |
Yes
|
| Protocol |
ArtNet, RDM, sACN
|
| Certifications |
CE, UKCA, cETLus
|
| Environmental Resistance |
Dust/Water-Resistant (IP66)
|
| Material of Construction |
Aluminum
|
| Cable Length |
4.9' / 1.5 m
|
| Dimensions |
9.5 x 7.1 x 3.2" / 242.0 x 180.0 x 82.0 mm
|
| Weight |
4 lb / 1.8 kg
|
All product and company names are trademarks or registered trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
