Description
NZXT H6 Flow Overview
- 1Description
- 2Dual-Chamber Design
- 3Fan and Radiator Compatibility
- 4Optimized Airflow
- 5Connectable Front I/O
Start your next build strong or give your current rig a new housing with the NZXT H6 Flow ATX Case in black. The panoramic layout features two tempered glass sides and an angled corner for front fans that give this case a unique aesthetic and clear view of the internal build. With room for an ATX, Micro-ATX, or Mini-ITX motherboard, as well as clearance for up to a 14.37" GPU, 7.87" PSU, and 6.42" CPU cooler, this case offers a wide variety of build options.
Dual-Chamber Design
This mid-tower case has two 2.5" drive bays and a 3.5" drive bay for extra storage, as well as support for vertical GPUs using a separately sold mount. With its dual-chamber setup, the power supply and additional storage are placed behind the motherboard, improving thermal performance for the CPU and GPU while creating a clean, uncrowded aesthetic.
Fan and Radiator Compatibility
This case's cooling capability is powered by space for up to nine fans. The front of the case supports up to three 120mm fans or one 360mm radiator. The top can support three 120mm or two 140mm fans, or a 360mm radiator. The bottom supports two 140mm fans and the rear supports one 120mm fan or radiator.
Optimized Airflow
Three 120mm fans come preinstalled with the case for efficient yet powerful cooling. Easily removable dust filters come on the top and front vents for cleaner airflow whether you have fans installed on every slot or not.
Connectable Front I/O
Along with power and reset buttons, the front of the case features two USB-A 3.2 Gen 1 ports, a USB-C 3.2 Gen 2 port, and a combo headphone/mic 3.5mm jack.
UPC: 810074844147
In the Box
- NZXT H6 Flow Mid-Tower Case (Black)
- Limited 2-Year Manufacturer Warranty
Table of Contents
- Description
- Dual-Chamber Design
- Fan and Radiator Compatibility
- Optimized Airflow
- Connectable Front I/O
NZXT H6 Flow Specs
Key Specs
| Motherboard Support |
ATX, Micro-ATX, Mini-ITX
|
| Internal Drive Bays |
2x 2.5"
and 1x 3.5" |
| Expansion Slots |
7x Full Height
|
| Maximum GPU Length |
14.4" / 365 mm
|
| CPU Cooler Height |
6.4" / 163 mm
|
| Fans Included |
Front:
3x 120 mm Non-LED (1200 rpm) |
| I/O |
1x USB-C (USB 3.1/3.2 Gen 2)
2x USB-A (USB 3.0 / 3.1/3.2 Gen 1) |
| Windowed Panel |
Yes
|
| Built-In Lighting |
Yes
|
| Tool-Less Design |
Thumbscrews
|
Compatibility
| Motherboard Support |
ATX, Micro-ATX, Mini-ITX
|
| External Drive Bays |
No
|
| Internal Drive Bays |
2x 2.5"
and 1x 3.5" |
| Expansion Slots |
7x Full Height
|
| Maximum GPU Length |
14.4" / 365 mm
|
| CPU Cooler Height |
6.4" / 163 mm
|
| Supported PSU Size |
ATX
|
| Maximum PSU Length |
7.9" / 200 mm
|
| PSU Mounting Location |
Bottom
|
Cooling
| Fan Mounting |
Front:
3x 120 mm Top: 3x 120 mm or 2x 140 mm Bottom: 2x 140 mm Rear: 1x 120 mm |
| Fans Included |
Front:
3x 120 mm Non-LED (1200 rpm) |
| Maximum Radiator Size |
Top:
360 mm Rear: 120 mm |
| Noise Level |
25.1 dBA
|
| Fan Controller Included |
No
|
| Filter Locations |
Front, Top
|
Inputs / Outputs
| I/O |
1x USB-C (USB 3.1/3.2 Gen 2)
2x USB-A (USB 3.0 / 3.1/3.2 Gen 1) |
| Media/Memory Card Slot |
No
|
| Audio I/O |
1x 3.5 mm Input/Output
|
| Display Outputs |
No
|
Physical
| Windowed Panel |
Yes
|
| Color |
Black
|
| Material |
Steel, Tempered Glass
|
| Built-In Lighting |
Yes
|
| Tool-Less Design |
Thumbscrews
|
| Security |
No
|
| Cable Management Space |
3.6" / 91 mm
|
| Dimensions (W x H x D) |
11.3 x 17.13 x 16.34" / 28.7 x 43.51 x 41.5 cm
|
| Weight |
20.7 lb / 9.4 kg
|
Packaging Info
| Package Weight |
24.215 lb
|
| Box Dimensions (LxWxH) |
20.3 x 20.2 x 14.1"
|
