Description
Product Overview
MCZ33781EK is a quad DSI 2.02 with differential drive and frequency spreading. It is a device for four differential DSI 2.02 buses. The differential mode of the 33781 generates lower electromagnetic interference (EMI) in situations where data rates and wiring make this a problem. Frequency spreading further reduces interference by spreading the energy across many frequencies, reducing the energy in any single frequency.
- Four independent differential DSI (DBUS) channels
- Dual SPI interface, enhanced bus fault performance
- Automatic message cyclical redundancy checking generation and checking for each channel
- 8 to 16bit messages with 0 to 8bit CRC
- Independent frequency spreading for each channel
- Pseudo bus switch feature on channel 0
- Supply voltage range from -0.3V to 26.5V
- 260°C soldering reflow temperature
- 1.0 ohm maximum pseudo bus switch matching (4.75V ? VCC ? 5.25V)
- 32 SOICW EP package, temperature range from -40°C to 90°C
Product details
Other details
| Brand | NXP |
| Part Number | MCZ33781EK |
| Quantity | Each |
| Technical Data Sheet EN |  |
