Product details
| Product Range:
HCS12X Family S12XD Series Microcontrollers
|
| Device Core:
HCS12X
|
| Data Bus Width:
16 bit
|
| Operating Frequency Max:
40MHz
|
| Program Memory Size:
256KB
|
| No. of Pins:
112Pins
|
| IC Case / Package:
LQFP
|
| No. of I/O's:
91I/O's
|
| Interfaces:
CAN, I2C, SCI, SPI
|
| RAM Memory Size:
16KB
|
| ADC Channels:
24Channels
|
| ADC Resolution:
10Bit
|
| Supply Voltage Min:
2.35V
|
| Supply Voltage Max:
2.75V
|
| Operating Temperature Min:
-40°C
|
| Operating Temperature Max:
85°C
|
| IC Mounting:
Surface Mount
|
| MCU Series:
S12XD
|
| MCU Family:
HCS12X
|
| Qualification:
-
|
| MSL:
MSL 3 - 168 hours
|
Other details
| Brand |
NXP |
| Part Number |
MC9S12XDT256VAL |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
