| ₹ 287.68 includes GST and import duties. | |
| B2B customers can avail ₹ 43.87 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The MC33662LEF is a Local Interconnect Network (LIN) designed to support automotive networks in conjunction with a controller area network (CAN). As the lowest level of a hierarchical network, LIN enables cost-effective communication with sensors and actuators when all the features of CAN are not required. It integrates a fast baud rate (above 100kbps), as reported by the RXD pin for test and programming modes. It provides excellent EMC (electromagnetic compatibility) and radiated emission performance, ESD (electrostatic discharge) robustness and safe behaviour, in the event of a LIN bus short-to-ground or a LIN bus leakage during low power mode. This device is powered by SMARTMOS technology.
- Active bus wave shaping, offering excellent radiated emission performance
- Very high immunity against electromagnetic interference
- Low standby current in Sleep mode
- Over-temperature protection
- Local and remote Wake-up capability reported by the RXD pin
- Fast baud rate selection reported by RXD pin
Automotive, Safety
Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.Other details
| Brand | NXP |
| Part Number | MC33662LEF |
| Quantity | Each |
| Technical Data Sheet EN |  |
| CAD CadSoft_EAGLE EN | |
| Product Change Notice EN | |
| Application Note EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 281.93 |
| 3-5 | ₹ 279.05 |
| 5-10 | ₹ 273.3 |
| 10+ | ₹ 267.54 |
Bulk discount will be automatically applied during checkout based on quantity.
