Description
The IL711-3E is a 2-transmit channel unidirectional 110Mbaud high-speed Digital Isolator CMOS device manufactured with NVEs patented IsoLoop® spintronic giant magneto resistive (GMR) technology. A unique ceramic/polymer composite barrier provides excellent isolation and virtually unlimited barrier life. The symmetric magnetic coupling barrier provides a typical propagation delay of only 10ns and a pulse width distortion as low as 300ps, achieving the best specifications of any isolator. Typical transient immunity of 50kV/µs is unsurpassed.
- Excellent magnetic immunity
- 150Mbps Typical high speed
- -40 to 125°C High temperature range
Applications
Communications & Networking, Medical
Product details
| Operating Temperature Min | -40°C |
| No. of Channels | 2 Channel |
| Operating Temperature Max | 100°C |
| Propagation Delay | 10ns |
| No. of Pins | 8Pins |
| Product Range | - |
| Automotive Qualification Standard | - |
| Interface Case Style | SOIC |
| Supply Voltage Min | 3V |
| Packaging | Each |
| Supply Voltage Max | 5.5V |
| MSL | MSL 2 - 1 year |
Other details
| Brand | NVE |
| Part Number | IL711-3E |
| Quantity | Each |
| Technical Data Sheet EN |  |
