Description
This is a Signal Relay, 24 V, DPDT, 2 A, EE2 Series, SMD, Non Latching product from NEXEM with the model number EE2-24NU-L
Product details
Coil Voltage | 24V |
Contact Configuration | DPDT |
Contact Current | 2A |
Product Range | EE2 Series |
Relay Mounting | SMD |
Coil Type | Non Latching |
Relay Terminals | Solder |
Contact Voltage VAC | 250V |
Contact Voltage VDC | 220V |
Contact Material | Silver Alloy |
Coil Resistance | 2.88kohm |
RoHS Phthalates Compliant | To Be Advised |
Other details
Brand | NEXEM |
Part Number | EE2-24NU-L |
Quantity | Each |
Technical Data Sheet EN | ![]() |
Product Change Notice EN | ![]() |
