Newline STV-7524-PLUS Overview
The Newline STV-7524-PLUS 75" UHD 4K Commercial Monitor is a 300 nits bright, LED LCD display with a thin 1.8mm bezel and 24/7 operation capability for an immersive visual experience in presentation and digital signage applications. The embedded Android 14 operating system provides ease of use and a suite of preloaded applications. The STV-7524-PLUS is designed to be compatible with a wide range of devices connecting via HDMI, USB, and Wi-Fi/LAN capability.
Digital Signage Capability
Digital Signage Compatibility is included with Newline VCS (Visual Communication Solution). Newline VCS is a digital broadcast network designed to unify visual communications in schools and businesses. Utilize your Newline display for all your digital signage and visual communication needs. Centrally manage the Newline STV+ in any location through a secure and dedicated web portal. Easily manage and deploy apps, configure Newline STV+ settings, use the digital signage features, or broadcast messages to all displays.
Additional Features
- Preloaded apps, including popular productivity tools
- Ultraslim 1.8mm left, right, and top bezel
- HDMI signal detection and auto switching
- Wake on LAN/Wi-Fi
- Auto power on/off
- Embedded USB media player
- Built-in Dual 10W speakers
Items Included
- Newline STV-7524-PLUS 75" UHD 4K Commercial Monitor
- Power Cord
- Remote Control with Batteries
- RCA Composite A/V Cable Adapter
- Limited 3-Year Manufacturer Warranty
Additional Resources
No additional resources available
Newline STV-7524-PLUS Specs
Key Specs
| Display Size |
75"
|
| Native Resolution |
3840 x 2160
|
| Maximum Brightness |
300 nits / cd/m2
|
| Inputs |
3x HDMI 2.0
1x RCA (Composite) |
| Outputs |
1x TOSLINK Optical (Digital Audio)
1x 1/8" / 3.5 mm (Analog Audio) |
| Wireless |
Wi-Fi 5 (802.11ac) / Bluetooth 5.0
|
| USB I/O |
1x USB-A 2.0
1x USB-A 3.0 / 3.1/3.2 Gen 1 |
| Ethernet I/O |
1x RJ45 (Unspecified Ethernet)
|
| Other I/O |
1x DE-9/DB-9 Serial (RS-232C) Control Input
|
| Built-In Speakers |
Yes, 2x 10 W
|
| Media Card Reader |
No
|
Display
| Display Size |
75"
|
| Panel Type |
LCD
|
| Aspect Ratio |
16:9
|
| Display Orientation |
Landscape
|
| Native Resolution |
3840 x 2160
|
| Maximum Brightness |
300 nits / cd/m2
|
| Contrast Ratio |
4000:1
|
| Response Time |
6.5 ms
|
| Refresh Rate |
60 Hz
|
| Color Support |
1.07 Billion Colors (8-Bit+FRC)
|
| Viewing Angle (H x V) |
178 x 178°
|
| Screen Area |
64.9 x 36.5" / 1648.5 x 927.1 mm
|
| Pixels Per Inch (ppi) |
59 ppi
|
| Finish |
Anti-Glare / Matte
|
Video
| TV Tuner |
No
|
Connectivity
| Inputs |
3x HDMI 2.0
1x RCA (Composite) |
| Outputs |
1x TOSLINK Optical (Digital Audio)
1x 1/8" / 3.5 mm (Analog Audio) |
| HDCP Support |
Yes
|
| Wireless |
Wi-Fi 5 (802.11ac) / Bluetooth 5.0
|
| USB I/O |
1x USB-A 2.0
1x USB-A 3.0 / 3.1/3.2 Gen 1 |
| Ethernet I/O |
1x RJ45 (Unspecified Ethernet)
|
| Other I/O |
1x DE-9/DB-9 Serial (RS-232C) Control Input
|
Speaker
| Built-In Speakers |
Yes, 2x 10 W
|
| Speaker Configuration |
2-Channel
|
Hardware
| Smart TV |
Android 14
|
| CPU |
Quad-Core: Cortex A73
|
| Storage |
16 GB
|
| RAM |
4 GB
|
| OS Compatibility |
Android/iOS
|
| Media Card Reader |
No
|
| Built-In Mic |
No
|
Electrical
| Power Consumption |
Typical: 190.0 W
Maximum: 250.0 W Network Standby: < 2.0 W Standby: < 0.5 W |
| Input Power |
110 to 240 VAC, 50 / 60 Hz
|
| Power Adapter Type |
Internal
|
General
| Operating Conditions |
32 to 104°F / 0 to 40°C at 20 to 80% Humidity
|
| Storage Conditions |
-4 to 140°F / -20 to 60°C up to 85% Humidity
|
| Mounting-Hole Pattern |
400 x 300 mm
|
| Impact Resistance |
No
|
| Bezel Thickness |
1.8 mm (Right/Top/Left)
20.3 mm (Bottom) |
| Duty Cycle |
24 Hours / 7 Days
|
| Dimensions |
65.7 x 37.6 x 3.5" / 1668 x 956.1 x 88.1 mm
|
| Weight |
50.07 lb / 22.71 kg
|
