Netgear GS524UP-100NAS Overview
-
1Description
-
2Power Auto-Balance & Allocation
-
3Energy Efficient
-
4Silent Operation
-
5Rugged Metal Casing
-
6Versatile Mounting Options
Integrate the Netgear GS524UP 24-Port PoE++ Compliant Gigabit Unmanaged Network Switch into your network to quickly expand your capacity for demanding power devices. Featuring 24 Gigabit speed Ethernet ports, 16 of which provide 60W PoE++ power output while the other eight support 30W, you can operate devices such as advanced IP cameras, high-bandwidth access points, and VoIP phones. Simply connect your devices to this unmanaged switch and Netgear's auto-balance and allocation technology will automatically detect each device's needs and distribute the 480W power budget accordingly.
The GS524UP ensures smooth data transfers with a 48 Gb/s non-blocking switching capacity and 1.4 Mpps forwarding rate. Its metal casing quickly dissipates heat, allowing the switch to operate efficiently and silently while resting on a desktop or mounted in a rack with the included hardware.
Power Auto-Balance & Allocation
Netgear's unique PoE technology automatically balances the PoE power, delivering exactly what each device needs.
This switch is designed to optimize power usage, lowering its cost to operate.
The fanless design means zero added noise wherever its located, making it ideal for your home or business environment.
Durable desktop case for longevity.
Versatile Mounting Options
Supports desktop or rackmount placement, and includes all mounting hardware.
In the Box
- Netgear GS524UP 24-Port PoE++ Compliant Gigabit Unmanaged Network Switch
- Power Cable
- Rackmount Kit
- 4 x Rubber Feet
- Limited Lifetime Warranty
Table of Contents
- Description
- Power Auto-Balance & Allocation
- Energy Efficient
- Silent Operation
- Rugged Metal Casing
- Versatile Mounting Options
Netgear GS524UP-100NAS Specs
Interfaces
| Inputs/Outputs |
8 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE+
16 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE (Type 3) |
Protocols
| Supported Protocols |
Auto-MDIX/MDI |
| Queuing |
Weighted Round Robin (WRR) |
| Jumbo Frames Support |
9216 Bytes |
| MAC Address Table Size |
8K |
Standards
| Supported IEEE Standards |
802.11ax, 802.1p, 802.3, 802.3ab, 802.3at, 802.3az, 802.3bt, 802.3i, 802.3u |
Performance
| Latency |
12 µs |
| Forwarding Rate |
1.4 Mpps |
| Switching Bandwidth |
48 Gb/s (Non-Blocking) |
| Packet Buffer |
192 Kb |
Electrical
| Power Draw |
24.4 W (Standby)
578.8 W (Max) |
| Current |
4 to 8 A |
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz |
| PoE Power Budget |
480 W |
| PoE per Port |
60 W |
| Power Supply Type |
Internal |
Environmental
| Operating Temperature |
32 to 122°F / 0 to 50°C |
| Operating Humidity |
10 to 90% (Non-Condensing) |
| Storage Temperature |
-4 to 158°F / -20 to 70°C |
| Storage Humidity |
10 to 95% (Non-Condensing) |
| Operating Altitude |
9842' / 3000 m |
| Storage Altitude |
9842' / 3000 m |
| Noise Level |
35.0 dB (Active) |
General
| Certifications |
UL62368-1, FCC47 CFR Part15B (Class A), ICES--003 Class A, EN55024/55032/55035 (Class A), VCCI, Kcc, CBIEC 60950-1, CBIEC 62368-1 Ed-3, BSMICNS14336-1, BSMICNS13438
*as per Manufacturer |
| Cooling System |
Fan |
| Mean Time Between Failures (MTBF) |
809,853 Hours |
| Material of Construction |
Metal |
| Indicator Lights |
Fan, Link/Activity, PoE, Speed |
| Dimensions |
15.4 x 8.7 x 1.7" / 390 x 220 x 43 mm |
| Weight |
6.83 lb / 3.1 kg |
Packaging Info
| Package Weight |
8.675 lb |
| Box Dimensions (LxWxH) |
19.1 x 12.9 x 3.8" |
