Netgear GS524PP Overview
-
1Description
-
2Power Auto Balance and Allocation
-
3Silent Operation
-
4Rugged Design
Expand your network with the Netgear GS524PP 24-Port Gigabit PoE+ Compliant Unmanaged Switch, which supports PoE devices, such as IP security cameras, VoIP phones, and access points. All 24 Gigabit Ethernet ports on this unmanaged switch are 30W PoE+ compliant for a total power budget of 300W. Netgear's power technologies help to ensure that the exact amount of power necessary is delivered to each connected PoE device. The GS524PP also has a 48 Gb/s switching capacity and a 1.448 Mpps forwarding rate to ensure fast, reliable performance. You can mount this switch onto a desktop or use the included kit for rackmount installations. Its plug-and-play design allows you to integrate the switch into your network without the need for any additional hardware or software.
Power Auto Balance and Allocation
With Netgear's PoE technology, this switch automatically delivers the exact amount of power each connected PoE device requires.
Silent Operation
The GS524PP is designed to operate silently with passive cooling until its two cooling fans are required to maintain optimal temperatures.
Rugged Design
This switch features a durable metal casing for enhanced longevity.
UPC: 606449149272
In the Box
- Netgear GS524PP 24-Port Gigabit PoE+ Compliant Unmanaged Switch
- Power Cable
- Rackmount Kit
- Desktop Rubber Feet Pack
- Insight Registration Flyer
- Limited Lifetime Warranty
- 90-Day Technical Support
- Limited Lifetime Online Chat Technical Support
Table of Contents
- Description
- Power Auto Balance and Allocation
- Silent Operation
- Rugged Design
Netgear GS524PP Specs
Interfaces
Ports |
24 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE+ |
Protocols
Supported Protocols |
Auto-MDIX/MDI |
Queuing |
Weighted Round Robin (WRR) |
Jumbo Frames Support |
9216 Bytes |
MAC Address Table Size |
8K |
Standards
Supported IEEE Standards |
802.1p, 802.2az, 802.3, 802.3ab, 802.3at, 802.3i, 802.3u |
Performance
Latency |
12 µs |
Forwarding Rate |
1.44 Mpps |
Switching Bandwidth |
48 Gb/s (Non-Blocking) |
Packet Buffer |
192 kB |
Electrical
Power Draw |
359.5 W (Max) 12.9 W (Standby) |
AC Input Power |
100 to 240 VAC, 50 / 60 Hz at 6 A |
PoE Power Budget |
300 W |
PoE per Port |
30 W |
Environmental
Operating Temperature |
32 to 122°F / 0 to 50°C |
Operating Humidity |
10 to 90% |
Storage Temperature |
-4 to 158°F / -20 to 70°C |
Storage Humidity |
10 to 95% |
Operating Altitude |
9842' / 3000 m |
General
Cooling System |
Fan |
Mean Time Between Failures (MTBF) |
1,457,063 Hours |
Material of Construction |
Metal |
Indicator Lights |
Link/Activity/Speed, PoE |
Rack Form Factor |
1 RU |
Dimensions |
15.4 x 8.7 x 1.7" / 390 x 220 x 43 mm |
Weight |
6.37 lb / 2.89 kg |
Packaging Info
Package Weight |
8.33 lb |
Box Dimensions (LxWxH) |
18.5 x 12.9 x 3.8" |
