Netgear GS324P-100NAS Overview
Boost the switching capacity of your small business with the GS324P 24-Port Gigabit PoE-Compliant Unmanaged Switch. Capable of up to 48 Gb/s of total switching bandwidth and a 1.44 Mpps forwarding rate, this desk- and rack-mountable unmanaged switch comes equipped with 24 Gigabit Ethernet ports. The ports support PoE (Power over Ethernet) with a 190W power budget, ideal for powering IP cameras, VoIP phones, wireless access points, and other PoE-capable devices.
Support for the Energy-Efficient Ethernet standard helps the plug-and-play switch to conserve power, while auto-MDI/MDIX support eliminates the need for crossover cables. The switch's 802.1p QoS capabilities allow for traffic prioritization, while its fanless design helps to ensure quiet operation.
LED indicators for ease of use
Auto-negotiation for automatic connection at the highest common speed between switch and an end device
Non-blocking switching architecture for maximum throughput at wire speed
Durable and rugged metal case
Ideal for small office and home networks
Standards-based technology helps to ensure interoperability with standards-based devices in the existing network
![]()
UPC: 606449144796
In the Box
- Netgear GS324P 24-Port Gigabit PoE-Compliant Unmanaged Switch
- Power Cable
- Limited 3-Year Warranty
Netgear GS324P-100NAS Specs
Interfaces
| Ports |
24 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE |
Protocols
| Supported Protocols |
Auto-MDIX/MDI
MAC Filtering |
| Queuing |
Weighted Round Robin (WRR) |
| Jumbo Frames Support |
10,000 Bytes |
| MAC Address Table Size |
8K |
Standards
| Supported IEEE Standards |
802.3, 802.3ab, 802.3az, 802.3i, 802.3u |
Performance
| Latency |
4 µs |
| Forwarding Rate |
1.44 Mpps |
| Switching Bandwidth |
48 Gb/s (Non-Blocking) |
| Packet Buffer |
192 kB |
Electrical
| Power Draw |
210.00 W (Active)
10.00 W (Standby) |
| AC Input Power |
110 to 240 VAC, 50 / 60 Hz at 8 A |
| PoE Power Budget |
190 W |
| PoE per Port |
30 W |
| Power Supply Type |
Internal |
Environmental
| Operating Temperature |
32 to 113°F / 0 to 45°C |
| Operating Humidity |
10 to 90% |
| Storage Temperature |
-4 to 158°F / -20 to 70°C |
| Storage Humidity |
10 to 95% |
| Operating Altitude |
10,000' / 3048 m |
General
| Cooling System |
Fan |
| Mean Time Between Failures (MTBF) |
1,193,574 Hours |
| Material of Construction |
Metal |
| Indicator Lights |
Fan, Link/Activity/Speed, PoE, Power |
| Dimensions |
13 x 8.1 x 1.7" / 330 x 206 x 43 mm |
| Weight |
5.38 lb / 2.44 kg |
Packaging Info
| Package Weight |
7.185 lb |
| Box Dimensions (LxWxH) |
16.4 x 11.8 x 4.1" |
