Netgear GS308EP-100NAS Overview
-
1Description
-
2Power over Ethernet
-
3VLAN Support
-
4Reliable Multicasts
-
5Security Features
-
6Diagnostics
-
7Link Aggregation
Quickly expand your small home or business network to support computers, storage, smart TVs, and more with the Netgear GS308EP 8-Port Gigabit PoE+ Compliant Unmanaged Switch. Featuring eight PoE+ compliant Gigabit Ethernet ports with a 62W budget, this compact unmanaged switch is designed to grow your network with support for powered devices such as IP cameras, VoIP phones, and access points. Its 16 Gb/s switching capacity helps to ensure smooth data transfers while support for VLAN traffic segmentation helps to secure access for connected devices. Simply connect the switch to your router and use the web-based configuration utility to get set up. No additional hardware devices or software drivers are required. Other features include QoS traffic prioritization for optimized audio and video communications and DoS attack prevention. The GS308EP has a fanless design with a metal chassis that allows it to operate silently when mounted onto a desktop or wall so that it won't disturb your working environment.
Power over Ethernet
Featuring eight PoE+ compliant Gigabit Ethernet ports with a 62W budget, the GS308EP can transfer both power and data with compatible devices. The integrated power management system allows you to enable or disable power for each port, limit the PoE power per port, and more. The PoE power stays on during firmware updates to provide an uninterrupted experience.
VLAN Support
Configure up to 64 VLANS to separate traffic and permissions into different groups.
Reliable Multicasts
The GS308EP supports up to 128 multicast groups, with features such as IGMP Snooping, rate limiting for bandwidth allocation, and Quality of Service (QoS) traffic prioritization to help ensure smooth video and audio traffic. Additionally, unknown multicasts can be blocked.
Security Features
Auto DoS (Denial-of-Service) attack prevention, Storm Control, Port Mirroring, and other features help to protect your network from attacks.
Diagnostics
Quickly troubleshoot connections with the cable testing utility.
Link Aggregation
Combine up to two ports using link aggregation to enhance the bandwidth and support multi-Gig connections to compatible devices.
UPC: 606449153026
In the Box
- Netgear GS308EP 8-Port Gigabit PoE+ Compliant Unmanaged Switch
- Power Adapter & Cable
- Wall Installation Kit
- Rubber Feet
- Limited 5-Year Warranty
- 90-Day Technical Support
Table of Contents
- Description
- Power over Ethernet
- VLAN Support
- Reliable Multicasts
- Security Features
- Diagnostics
- Link Aggregation
Netgear GS308EP-100NAS Specs
Interfaces
Ports |
8 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE+ (Type 2) |
Protocols
Supported Protocols |
IGMP Snooping Link Aggregation Port Mirroring |
Queuing |
Weighted Round Robin (WRR) |
Transmission Method |
Store-and-Forward |
Jumbo Frames Support |
9216 Bytes |
MAC Address Table Size |
4K |
Multicast Groups |
128 |
VLAN IDs |
64 |
Security
Security Features |
DoS Attack Prevention Storm Control |
Standards
Supported IEEE Standards |
802.1p, 802.1q, 802.3, 802.3ab, 802.3af, 802.3at, 802.3az, 802.3u, 802.3x |
Performance
Switching Bandwidth |
16 Gb/s |
Packet Buffer |
192 kB |
Electrical
PoE Power Budget |
62 W |
PoE per Port |
30 W |
Power Supply Type |
External |
Environmental
Operating Temperature |
32 to 104°F / 0 to 40°C |
Operating Humidity |
90% |
Storage Temperature |
-4 to 158°F / -20 to 70°C |
Storage Humidity |
95% |
Operating Altitude |
10,000' / 3048 m |
Storage Altitude |
10,000' / 3048 m |
Noise Level |
0.0 dB |
General
Cooling System |
Passive |
Mean Time Between Failures (MTBF) |
859,126 Hours |
Material of Construction |
Metal |
Indicator Lights |
Link/Activity/Speed, PoE, Power |
Dimensions |
6.2 x 4 x 1.1" / 158 x 101 x 27 mm |
Weight |
1.08 lb / 0.49 kg |
Packaging Info
Package Weight |
2.5 lb |
Box Dimensions (LxWxH) |
10.4 x 6.6 x 3.4" |
