Netgear GS305E-100NAS Overview
Quickly expand your small home or business network to support computers, storage, video game consoles, smart TVs, and other devices with the Netgear GS305E 5-Port Gigabit Managed Switch. With five Gigabit Ethernet ports, support for VLAN traffic segmentation, and a plug-and-play design, this compact managed switch is built to quickly grow your network. Simply connect the switch to your router and use either the web-based configuration utility or PC app to get set up. No additional hardware device or software drivers are required, and its 10 Gb/s switching capacity helps to ensure smooth data transfers. Other features include QoS traffic prioritization for optimized audio and video communications and DoS attack prevention. The GS305E has a fanless design that allows it to operate silently when mounted onto a desktop or wall so that it won't disturb your working environment.
VLAN Support
Configure up to 64 VLANS to separate traffic and permissions into different groups.
Reliable Multicasts
The GS305E supports up to 128 multicast groups, with features such as IGMP Snooping, rate limiting for bandwidth allocation, and Quality of Service (QoS) traffic prioritization to help ensure smooth video and audio traffic. Additionally, unknown multicasts can be blocked.
Security Features
Auto DoS (Denial-of-Service) attack prevention, Storm Control, and other features help to protect your network from attacks.
Diagnostics
Quickly troubleshoot connections with the cable testing utility.
![]()
UPC: 606449140521
In the Box
- Netgear GS305E 5-Port Gigabit Managed Switch
- Power Adapter
- Limited 5-Year Warranty
- 90-Day Technical Support
Table of Contents
- Description
- VLAN Support
- Reliable Multicasts
- Security Features
- Diagnostics
Netgear GS305E-100NAS Specs
Interfaces
| Ports |
5 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) |
Protocols
| Layer Services Supported |
Layer 2 Support, Layer 3 Support |
| Supported Protocols |
Auto-MDIX/MDI
IGMP Snooping
Port Mirroring |
| Queuing |
Strict Priority, Weighted Round Robin (WRR) |
| Transmission Method |
Store-and-Forward |
| Jumbo Frames Support |
9000 Bytes |
| MAC Address Table Size |
8K |
| Multicast Groups |
128 |
| VLAN Groups |
64 |
Security
| Security Features |
DoS Attack Prevention
Kensington Lock Support
Storm Control |
Standards
| Supported IEEE Standards |
802.1p, 802.1q, 802.3, 802.3ab, 802.3u, 802.3x |
Performance
| Switching Bandwidth |
10 Gb/s |
| Packet Buffer |
128 kB |
Environmental
| Operating Temperature |
32 to 122°F / 0 to 50°C |
| Operating Humidity |
90% |
| Storage Temperature |
-4 to 158°F / -20 to 70°C |
| Storage Humidity |
95% |
| Operating Altitude |
10,000' / 3048 m |
| Storage Altitude |
10,000' / 3048 m |
General
| Cooling System |
Passive |
| Mean Time Between Failures (MTBF) |
2,531,294 Hours |
| Indicator Lights |
Link/Activity/Speed, System/Power |
| Dimensions |
3.9 x 3.7 x 1.1" / 100 x 94 x 27 mm |
| Weight |
0.55 lb / 0.25 kg |
Packaging Info
| Package Weight |
1.15 lb |
| Box Dimensions (LxWxH) |
9.4 x 6.1 x 2.3" |
