General |
Device Type | KVM / audio / USB extender |
Form Factor | External |
Networking |
Connectivity Technology | Wired |
Max Resolution | 1920 x 1200 @ 60 Hz |
Max Video Bandwidth | 300 MHz |
Max Transfer Distance | 328 ft |
Status Indicators | Link activity, power, diagnostic |
Features | Power over Ethernet (PoE), built-in DIP switch, 1080p resolution support |
Compliant Standards | IEEE 802.3af, DVI 1.0, HDCP 1.4 |
Expansion / Connectivity |
Interfaces | 1 x DVI-D (input) female 1 x USB - Type B female 1 x network - RJ-45 female 1 x audio (input) - mini jack female 1 x audio (output) - mini jack female |
Power |
Power Over Ethernet (PoE) | PoE |
Power Consumption Operational | 2.85 Watt |
Environmental Parameters |
Min Operating Temperature | 32 �F |
Max Operating Temperature | 104 �F |
Humidity Range Operating | 0 - 95% (non-condensing) |
