| General |
| Device Type | KVM / audio / USB extender |
| Form Factor | External |
| Networking |
| Connectivity Technology | Wired |
| Max Resolution | 1920 x 1200 @ 60 Hz |
| Max Video Bandwidth | 300 MHz |
| Max Transfer Distance | 328 ft |
| Status Indicators | Link activity, power, diagnostic |
| Features | Power over Ethernet (PoE), built-in DIP switch, 1080p resolution support |
| Compliant Standards | IEEE 802.3af, DVI 1.0, HDCP 1.4 |
| Expansion / Connectivity |
| Interfaces | 1 x DVI-D (output) female
2 x USB - Type A female
2 x USB 2.0 - Type A female
1 x network - RJ-45 female
1 x audio (output) - mini jack female
1 x microphone (input) - mini jack female |
| Power |
| Power Over Ethernet (PoE) | PoE |
| Power Consumption Operational | 2.55 Watt |
| Environmental Parameters |
| Min Operating Temperature | 32 �F |
| Max Operating Temperature | 104 �F |
| Humidity Range Operating | 0 - 95% (non-condensing) |
